Overview
The ISSC D-16-09-002 Rev G is an AC switch output relay board engineered for reliable operation in industrial automation and control systems. Manufactured by Kanson Electronics (ISSC), this module integrates solid-state switching technology with traditional relay functionality, making it suitable for applications requiring dependable AC load control. The board’s compact form factor and proven design enable straightforward integration into existing machinery control cabinets and distributed control architectures.
Key Features
- Solid-state AC switch output technology for enhanced reliability and reduced contact wear
- General-purpose relay function compatible with standard industrial control logic
- Compact PCB design for efficient cabinet space utilization
- Tested and functional industrial-grade control component
- Revision G specification ensures design maturity and field-proven performance
Technical Specifications
Detailed specifications for this relay board module are best confirmed with your system integrator or directly via Kanson Electronics technical support (800-233-9354). Typical ISSC relay boards in this series support operating voltages from 12 VDC to 240 VAC and feature:
- Output type: AC switch relay contact
- Solid-state switching architecture
- LED status indicators for power and contact monitoring
- Industrial operating temperature range
- Standard PCB mounting configuration
Typical Applications
- Motor starter and pump control circuits
- Solenoid valve actuation for pneumatic and hydraulic systems
- Load switching and distribution in process automation
- Control logic sequencing for manufacturing equipment
- HVAC and facility management system relay functions
- Integration into legacy and modern PLC-based control systems
Compatibility & Replacements
Compatible With
- Industrial control systems and PLC architectures using relay-based I/O
- Distributed control panels and equipment logic circuits
- Standard 24 VDC and 120/240 VAC control power systems
- Kanson Electronics / ISSC relay module ecosystems
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. The D-16-09-002 Rev G supersedes earlier revisions of the same model. Specific replacement part numbers should be confirmed with Kanson Electronics technical support.
Works With
- Industrial relay-based control architectures (non-networked)
- Wired logic control circuits and hardwired interlocking systems
- Traditional machine tool and manufacturing control panels
- Standard electrical enclosures and DIN-rail mounting systems
