Overview
The Illinois Capacitor 106RLR035KPX is a radial-lead aluminum electrolytic capacitor in the RLR series, offering 10µF capacitance at 35V working voltage. This pack contains 400 units, making it suitable for OEM assembly lines, repair shops, and component resellers. The radial termination design allows straightforward through-hole PCB insertion and wave soldering.
Key Features
- Capacitance: 10µF ±20% tolerance
- Voltage Rating: 35V DC working voltage
- Termination: Radial leads (RLR series)
- Package: 400-unit pack for high-volume applications
- Temperature Range: Suitable for standard industrial and consumer electronics
- Lead-free compliant construction for modern PCB processes
Technical Specifications
Illinois Capacitor RLR series radial aluminum electrolytics are engineered for reliability in bypass, coupling, and filtering applications. Standard industrial operating temperature ranges and lead spacing ensure drop-in compatibility with legacy and modern PCB designs. The ±20% tolerance and stable voltage derating characteristics make these capacitors predictable in circuit analysis.
Typical Applications
- Power supply bypass and decoupling circuits
- Audio equipment and amplifier coupling stages
- Industrial control and automation circuits
- Consumer electronics assembly and OEM production
- Component stockpiling and device repair inventory
Compatibility & Replacements
Compatible With
- Standard PCB through-hole footprints with 5mm or 7.5mm radial lead spacing
- Wave soldering equipment for mass production
- Hand soldering and rework stations
- Industrial power supplies and audio amplifier designs
Replaces / Drop-In Replacement For
The 106RLR035KPX shares the same physical dimensions and electrical ratings as the standard 106RLR035M variant. Verify pin spacing and height clearance in your PCB design before substitution. Consult Illinois Capacitor’s technical data or your system integrator for equivalent part cross-references.
Works With
- Standard EIA (Electronic Industries Alliance) footprint standards
- RoHS and lead-free PCB assembly processes
- IPC (Institute for Printed Circuits) J-STD-001 soldering specifications
- Automated and manual assembly lines
