Overview
The Heinemann HB2-533-XBX is a Silic-O-Netic electronic time delay relay manufactured by Eaton Cutler-Hammer. This general-purpose relay delivers reliable control logic and timing functions in industrial and commercial automation systems. The vertical mounting configuration with standard 8-pin socket ensures compatibility with DIN-rail and panel-mounted installations across a wide range of control applications.
Key Features
- Silic-O-Netic technology for solid-state switching reliability and extended service life
- 3-second adjustable time delay enables precise timing control for automation sequences
- DPDT (Double Pole, Double Throw) contact configuration for flexible relay logic
- 120VAC coil voltage for standard industrial control circuits
- 8-pin vertical socket mount for compact panel and DIN-rail integration
- General-purpose relay design suitable for motor starters, solenoids, and control circuits
Technical Specifications
- Coil Voltage: 120VAC
- Contact Configuration: DPDT (Double Pole, Double Throw)
- Time Delay: 3 seconds
- Mounting Style: Vertical, 8-pin socket
- Diameter: 2 inches
- Height: 2.8 inches
- Technology: Silic-O-Netic (solid-state)
- Application Category: General-purpose time delay control relay
Typical Applications
- Motor control and soft-start sequencing
- Solenoid valve and actuator delay circuits
- Industrial pump and compressor startup timing
- Alarm and indication light delay logic
- Sequential timing and interlock functions in process control
- HVAC and automation panel control systems
Compatibility & Replacements
Compatible With
- Standard 8-pin relay sockets and DIN-rail mountable enclosures
- Industrial control panels operating at 120VAC
- Allen-Bradley, Siemens, Omron, and general-purpose automation platforms
- Motor starters, programmable controllers, and hardwired logic systems
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator or consult original equipment documentation before ordering. The HB2-533-XBX is designed to replace equivalent Heinemann HB2-series time delay relays in 120VAC applications with 8-pin socket mounting.
Works With
- Standard 8-pin industrial relay sockets
- 120VAC single-phase control circuits
- Hardwired control logic and automation systems
- DIN-rail mounted control enclosures
