Overview
The GV2 MC02 is a TeSys GV2 surface mount enclosure for TeSys GV2ME, IP55 rated. Manufactured by Schneider Electric (branded as Telemecanique), this compact control enclosure is engineered for manual motor starter installation in industrial control systems. The unit provides environmental protection suitable for harsh manufacturing environments while maintaining compatibility with the full GV2ME product family.
Key Features
- IP55 rated surface mount enclosure for TeSys GV2ME manual starter & protector
- White polyester body construction with wall mount design
- Left and right auxiliary mounting locations for flexible installation
- Compact footprint suitable for space-constrained control panels
- Full compatibility with GV2ME controls motors with full load currents up to 32 A
Technical Specifications
The GV2 MC02 delivers precise dimensional and electrical ratings for OEM panel builders and end-user installations:
Typical Applications
The GV2 MC02 enclosure is ideally suited for:
- Industrial motor control panel enclosures
- Manufacturing equipment starter protection housings
- HVAC and pump motor starter installations
- Process automation control systems requiring IP55 environmental sealing
- Retrofit installations for existing GV2ME-based systems
Compatibility & Replacements
Compatible With
- TeSys GV2ME product range
- Schneider Electric GV2 Series manual motor starters
- Industrial motor control systems (manual starter applications)
- Panel mounting for single-phase and three-phase motors
Replaces / Drop-In Replacement For
The GV2 MC02 serves as the direct enclosure solution for GV2ME installations. For specific legacy model replacements, verify compatibility with your system integrator before ordering.
Works With
- GV2 and GV3 manual starter and protector products; GV2ME, GV2P, GV3ME and GV7 product family
- Standard industrial control system wiring practices
- IEC 60947-2 compliant motor control systems
- Standard terminal and device mounting hardware (included)
