Overview
The GE WR60X26866 is a critical component in GE refrigerators, designed to circulate cold air over the evaporator coils and distribute it evenly throughout the fresh food and freezer compartments. Operating as a DC motor, it ensures consistent internal temperatures by drawing air across the cooling coils and pushing it through the unit. This genuine OEM part is a direct replacement for failed or underperforming evaporator fans.
Key Features
- Engineered with high-quality materials for long-lasting performance and quiet operation
- Pulls air through the evaporator coils to remove heat from the circulating air within the unit
- Axial fan used in the fresh food section of some french door units
- Includes axial fan assembly with color-coded harness
- Compact size for easy installation
Technical Specifications
- Voltage: 13.6VDC
- Current: 0.16A
- Fan Housing Dimensions: 3-4/7″L x 2″W x 3-1/8″H
- Harness & Plug Length: 11-1/2″L
- Material: Plastic and metal construction
- Color: Black with multi-colored harness
- Type: Evaporator fan motor assembly
Typical Applications
This evaporator fan motor is used for some GE refrigerator models. While primarily used in GE models, it is also compatible with select units from Hotpoint, Café, and Monogram. Common symptoms of a failing evaporator fan include poor cooling performance, frost buildup in the freezer, or unusual noises from the refrigerator. Replacing a faulty motor restores optimal airflow and cooling efficiency.
Compatibility & Replacements
Compatible With
- General Electric (GE) refrigerator models
- Hotpoint refrigerator models
- Café refrigerator models
- Monogram refrigerator models
Replaces / Drop-In Replacement For
- WR60X10341, WR60X10356, WR60X24303, WR60X26030, WR60X26033, WR60X10357
- 239D1412P006, V80E14MS2A3-57A611, 8817V-W1, 4546026, AP6278228
- EAP12172983, PD00038765, PS12172983
Works With
- GE refrigerator fresh food compartments
- Freezer compartment air distribution systems
- Evaporator coil cooling circuits
