Overview
The Festo MFL-110-60 is a compact indicator insert engineered to provide visual confirmation of circuit status in pneumatic and solenoid coil systems. Model 10634, this 110VAC insert delivers dependable feedback for maintenance and operational monitoring across industrial automation applications. Its lightweight design and standardized form factor enable fast integration with Festo F-coils and related pneumatic control components.
Key Features
- 110VAC nominal operating voltage (±10% tolerance)
- Compact form factor fits standard Festo F-coil mounting
- 220 mW power consumption at 50–60 Hz operation
- IP64 protection rating (IP40 without gasket)
- Zener diode protective circuit prevents coil voltage spikes
- Temperature range -5 to +40°C (+23 to +104°F)
Technical Specifications
| Voltage Rating | 110VAC ±10% |
| Frequency | 50–60 Hz |
| Power Consumption | 220 mW |
| Protection Rating | IP64 (with gasket) |
| Operating Temperature | -5 to +40°C |
| Weight | 0.024 lb (0.011 kg) |
| Dimensions (Width × Height) | 21.5 mm × 50 mm |
| Protective Circuit | Zener diode ZY 47 20W |
| Part Number | MFL-110-60 / 10634 |
| Manufacturer | Festo |
Typical Applications
- Pneumatic valve solenoid coil status indication
- Electrical circuit monitoring in control panels
- Visual feedback for machine automation sequences
- System integrator installations requiring panel-mounted indicators
- Retrofits and replacement of existing indicator inserts
Compatibility & Replacements
Compatible With
- Festo F-coil solenoid assemblies (MFH, MFFH, MSSD, MSSD-F series)
- Standard pneumatic directional and proportional valve coils
- Industrial electrical control panels with 110VAC supply
- 50–60 Hz power systems
Replaces / Drop-In Replacement For
- MFL-110AC-60 (alternate part designation)
- Previous versions of Festo 110VAC indicator inserts with F-coil mounting
Works With
- Festo pneumatic automation systems
- Zener diode surge protection (standard in design)
- 50/60 Hz commercial AC power supplies
