Overview
The Festo DGSL-16-150-PA is a double-acting guided pneumatic mini slide ideal for applications requiring high precision linear motion. This DGSL series mini slide features a 16 mm piston diameter and 150 mm stroke with 1-8 bar operating range and progressive shock absorber at both ends. The compact guided design provides excellent load capacity while maintaining maximum positioning accuracy.
Key Features
- High load capacity and positioning accuracy
- Maximum movement precision thanks to ground-in ball bearing cage guide
- Double-acting operation for forward and return control
- Reliable in the event of pressure drop thanks to clamping cartridge or end-position locking
- Wide variety of mounting and attachment options
- Compact design
Technical Specifications
- Piston Diameter: 20 mm
- Stroke Length: 150 mm
- Operating Pressure Range: 1–8 bar
- Actuation Type: Double-acting pneumatic
- Bearing Guide: Ball bearing cage guide
- Shock Absorption: Progressive shock absorber at both ends
- Pneumatic Connection: M5
Typical Applications
The Festo DGSL-16-150-PA is widely used in:
- Precision assembly and handling equipment
- Machine tool automation
- Laboratory and test equipment
- Packaging machinery
- Industrial positioning systems
- Robotics integration
Compatibility & Replacements
Compatible With
- Standard pneumatic control systems (1–8 bar)
- Festo solenoid valve controllers
- Directional control valves with M5 pneumatic ports
- Industrial PLC-based automation platforms
Replaces / Drop-In Replacement For
- Festo DGSL-16-150-Y3A (alternate model, 544004)
- Similar stroke/bore guided cylinders in the DGSL series
Works With
- Festo pneumatic control systems
- Standard ISO 4401 directional control valves
- M5 push-in connectors for tubing (4 mm OD)
- Flow control and shuttle valve assemblies
