Overview
The Eaton CSNS3A3CY2402 is a photoelectric sensor connector cable engineered for reliable M8 signal connectivity in industrial control and automation environments. This cable features a nano-style straight female 3-wire connector with brown/blue/black wiring, 24 AWG conductors, PVC jacket, and 100 Vdc rating. The flying-leads design enables direct termination to control modules, PLCs, and barrier-strip connections without requiring additional adapters.
Key Features
- M8 female 3-pin connector, straight orientation
- 3-wire configuration: brown, blue, black per IEC wiring standards
- 24 AWG conductor gauge with 6.6 ft (2 m) cable length
- PVC jacket for general industrial use
- 100 Vdc rated connector system
- Flying leads for barrier-strip or direct screw-terminal connection
- Designed for photoelectric and proximity sensors
Technical Specifications
- Connector Type: M8 Female, 3-pin, straight
- Conductor Size: 24 AWG (0.25 mm²)
- Cable Length: 6.6 ft (2 m)
- Wire Configuration: 3-wire (brown, blue, black)
- Jacket Material: PVC
- Voltage Rating: 100 Vdc
- Connector Coding: Standard A-encoded M8
- Contact Plating: Nickel plated copper alloy
Typical Applications
The CSNS3A3CY2402 is commonly specified for:
- Eaton Global Plus photoelectric sensor systems
- Inductive proximity sensor field wiring
- Industrial control cabinet installations
- Retrofit and replacement installations in existing sensor networks
- OEM equipment integration for automated machinery
- Factory automation and assembly line applications
Compatibility & Replacements
Compatible With
- Eaton Global Plus photoelectric sensors (E3D, E3S, E3U series)
- Eaton M8 3-pin sensor connectors and receptacles
- Standard A-encoded M8 industrial sensor systems
- Industrial control module barrier-strip terminals
- PLC analog and discrete input cards with M8 connectors
- DIN-rail mounted M8 junction boxes and splitters
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. The CSNS3A3CY2402 supersedes earlier Eaton sensor cable models with the same M8 female 3-pin configuration and 2 m cable length.
Works With
- Eaton iProx sensor programming and configuration software
- Eaton Global Plus sensor line accessories and connectors
- Standard IEC 61076-2-109 M8 connector ecosystems
- Industrial automation platforms: Rockwell Automation, Siemens, Beckhoff, Omron
- All standard A-encoded M8 sensor and actuator systems
