Overview
The Dodge 244093 is a twin-tapered bushing assembly engineered for precision mounting in Torque-Arm TXT4 speed reducers. Built from Class 65 ductile iron, this bushing provides reliable dual-sided support, maximum torque handling, and shock load capability for demanding industrial applications. The tapered design ensures a tight, repeatable clamp fit without setscrew complications.
Key Features
- Twin-tapered design for symmetrical load distribution and reduced shaft wobble
- Full-length integral shaft key for positive drive engagement
- Flanged bushing mount with fully split construction for fast installation and removal
- Clamp-fit design that eliminates fretting and seizing problems
- Shock-resistant ductile iron (Class 65) construction
- Supports both sides of reducer simultaneously with maximum torque and shock load capability
- Removal screws for reliable demount without damage to driven shaft
Technical Specifications
- Bore Diameter: 1.9375 inches (1-15/16 inch nominal)
- Bore Length: 9.3125 inches
- Bushing Type: Twin-Tapered
- Material: Ductile Iron, Class 65
- Rated Torque: 17,020 inch-pounds
- Installation Torque: 360 inch-pounds
- Number of Bolts: 6
- Integral Key: Yes, full-length shaft key
- Weight: 7.32 lbs
- Manufacturer Part Number: 244093
Typical Applications
The Dodge 244093 bushing is ideal for industrial power transmission systems using Torque-Arm speed reducers, including conveyor drives, material handling equipment, industrial gearbox installations, and heavy-duty torque transmission where shock loads and undersized shafts require precision mounting and vibration reduction.
Compatibility & Replacements
Compatible With
- Torque-Arm TXT4 Speed Reducer
- Torque-Arm II (TA-II) Speed Reducer systems
- Twin-tapered bushing compatibility standard across TXT4 family
- Industrial gearbox applications requiring 1-15/16 inch bore mounting
Replaces / Drop-In Replacement For
- Dodge TDT4X1-15/16 tapered bushing assemblies
- OEM Torque-Arm TXT4 original equipment bushings
- Verify compatibility with your specific speed reducer model before ordering
Works With
- Dodge mechanical power transmission solutions and reliability kits
- Torque-Arm TXT4 double-reduction and single-reduction configurations
- Industrial motor-to-reducer mounting systems
- Baldor and ABB motor coupling applications
