Overview
The Dodge 100564 sprocket (designation 60BTL13H-1210) is a Taper-Lock single-strand roller chain sprocket engineered for high-shock-load applications. This new-condition unit combines proven Dodge engineering with dependable chain drive performance, making it suitable for industrial machinery, conveyor systems, and power transmission applications requiring robust torque transfer and minimal maintenance.
Key Features
- Taper-Lock Bushing Mount — Automatically compensates for shaft and sprocket machining tolerances without expensive re-matching or alignment work.
- Compact Design — No protruding flanges or screw-heads; saves valuable shaft space for more power-dense assemblies.
- High-Shock Load Rating — Roller chain drives handle shock loads and deliver dependable performance in demanding duty cycles.
- Single-Strand Rated — Standard single-strand chain compatibility for standard industrial power transmission.
- Low-Carbon Steel Construction — Durable material composition for long service life and reliable performance.
- New in Box Condition — Factory-sealed, ready for immediate installation.
Technical Specifications
The following specifications apply to the Dodge 100564 60BTL13H-1210 sprocket:
- Part Number: 100564
- Model Designation: 60BTL13H-1210
- Type: BTL (Taper-Lock, Single-Strand)
- Chain Pitch: 1-1/4 inch (60BTL = 1.25″ pitch)
- Material: Low-Carbon Steel
- Mounting Style: Taper-Lock Bushing (QD or Solid Bore available with bushing)
- Condition: New in Box
- Manufacturer: Dodge (Baldor / ABB)
Typical Applications
- Industrial conveyor and material handling systems
- Manufacturing machinery and production equipment
- Fan and blower drive systems
- Pump and compressor coupling
- Textile, printing, and packaging machinery
- Agricultural and construction equipment power transmission
Compatibility & Replacements
Compatible With
- 60 Pitch roller chain (#60 standard and heavy-duty chain)
- 1-1/4 inch (60 BTL) pitch chain drive systems
- Dodge QD bushings and solid-bore adapters
- Standard shaft sizes (verify bore range with system design)
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. Cross-reference with OEM documentation or contact Dodge/Baldor technical support to confirm interchangeability with your specific equipment.
Works With
- #60 Roller Chain (standard and heavy-duty grades)
- Dodge Taper-Lock Bushings (QD or solid-bore types)
- Standard industrial motor and gearbox couplings
- Industrial power transmission systems (motors, gearboxes, reducers)
