Overview
The Dodge 100580 sprocket 60BTL32H-2012 is a single-row taper lock roller chain sprocket engineered for dependable mechanical power transmission. With 32 teeth and heat-treated construction, this sprocket delivers consistent performance in conveyor systems, pump drives, fan motors, and other industrial equipment requiring #60 roller chain engagement.
Key Features
- 32 teeth designed for #60 roller chain compatibility
- Taper lock design with #2012 bushing bore for secure mounting
- Heat-treated construction for enhanced durability
- Precision-machined for smooth, quiet operation
- Heavy-duty industrial-grade power transmission component
Technical Specifications
The sprocket offers the following dimensions and performance characteristics for integration into standard mechanical drive systems:
- Outside Diameter: 8.07 inches
- Pitch Diameter: 7.652 inches
- Tooth Count: 32 teeth
- Chain Size: #60 roller chain
- Bushing Type: Taper lock #2012 (sold separately)
- Weight: Approximately 6.0 lbs
- Material: Heat-treated steel
- Bore Style: Taper lock mechanism
Typical Applications
The Dodge 100580 is commonly used in:
- Conveyor drive systems
- Centrifugal pump motors
- Fan and blower applications
- Industrial mixers and agitators
- Compressor and vacuum pump drives
- Textile and paper machinery
- Food processing and packaging equipment
Compatibility & Replacements
Compatible With
- #60 roller chain standard dimensions
- Dodge taper lock bushings (Series #2012)
- ANSI B29.1 standard #60 chain drives
- Industrial mechanical power transmission systems rated for 32-tooth sprocket engagement
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. This part is a direct OEM Dodge component and substitutes for applications originally equipped with Dodge 100580 sprockets.
Works With
- #60 ANSI roller chain
- Dodge taper lock bushings and hubs
- Standard mechanical drive couplings rated for sprocket power transmission
- Belt-to-chain or chain-to-chain mechanical drive configurations
