Overview
The Gates 7726-3040 PolyChain GT sprocket is engineered for reliable synchronous power transmission in industrial machinery. With its proven split-hub (SH) design and PolyChain GT belt compatibility, this sprocket delivers consistent performance in repetitive-duty applications requiring precision timing and minimal maintenance.
Key Features
- 40-tooth PolyChain GT sprocket with 8M pitch for synchronous belt drive compatibility
- Split-hub (SH) design for tool-free assembly and removal without bearing or motor displacement
- 36mm bore accommodates standard shafts with minimal setup time
- Durable steel construction rated for maximum 7780 RPM continuous duty
- Reduces downtime through quick changeover maintenance procedures
Technical Specifications
- Manufacturer: Gates
- Part Number: 7726-3040
- Teeth: 40
- Pitch: 8M (8mm)
- Belt Width: 40mm
- Bore Diameter: 36mm
- Hub Style: Split Hub (SH)
- Maximum RPM: 7780
- Material: Steel
- Condition: New in Box
Typical Applications
The Gates 7726-3040 is suited for:
- Industrial conveyor systems requiring precise belt synchronization
- Packaging and printing machinery
- Food processing equipment
- Material handling and automation systems
- Machine tool drives operating at moderate to high speeds
Compatibility & Replacements
Compatible With
- Gates PolyChain GT belts with 8M pitch
- Standard shaft mounting with 36mm bore specification
- Industrial power transmission systems using synchronous belt drive
- Machinery designed for split-hub sprocket configuration
Replaces / Drop-In Replacement For
This sprocket is a direct replacement for OEM applications specifying Gates part number 7726-3040 or equivalent 8M-40S-36 PolyChain GT sprockets with split-hub mounting. Verify compatibility with your system integrator before ordering.
Works With
- Gates PolyChain GT synchronous belt systems
- Split-hub coupling systems for flexible shaft mounting
- Standard industrial motor and drive configurations
- Precision machinery requiring timed belt drive operation
