Overview
The Bimba Z711510064871 is a double-acting single-rod pneumatic cylinder from the Original Line series. Designed for compressed-air linear motion control, this 14DP model features a 1″ bore and 1″ stroke length, making it suitable for general industrial automation, material handling, clamping, and positioning applications requiring dependable, maintenance-free pneumatic actuation.
Key Features
- Double-acting configuration for controlled extend/retract cycles
- Original Line® design—industry-standard, non-repairable construction proven for longevity
- Standard bore size (1″) with single-rod design for compact mounting
- 1″ stroke length optimized for tight-space installations
- Permanent grease lubrication—no additional oiling required during service
- Wide variety of mounting styles and port configurations available
Technical Specifications
- Manufacturer: Bimba (IMI Norgren)
- Part Number: Z711510064871
- Model Designation: 14DP
- Bore Diameter: 1″
- Stroke Length: 1″
- Piston Action: Double-acting
- Rod Type: Single-rod
- Maximum Pressure: 250 psi
- Operating Fluid: Compressed air (clean, dry air recommended)
- Seal Material: Buna-N standard (fluoroelastomer high-temperature option available)
- Operating Temperature Range: Standard –20°F to +200°F (extended options available)
Typical Applications
Pneumatic cylinders in the 1″ bore class are widely used in industrial automation for:
- Automated clamping and workholding fixtures
- Material handling and parts transfer systems
- Linear positioning in assembly machinery
- Press and ejector applications
- Feed mechanisms and conveyors
- General-purpose automation where compact, low-cost actuation is required
Compatibility & Replacements
Compatible With
- Standard pneumatic systems operating at 250 psi or below
- Industrial compressed air systems with proper filtration and drying
- Standard NPT and UNF-threaded pneumatic port configurations
- P4 and P3 valve manifolds compatible with Original Line mounting footprints
- Proportional and directional control valves rated for continuous duty
- Standard pneumatic tubing (1/4″, 3/8″, 1/2″ NPT)
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. The Bimba Z711510064871 is a direct replacement for units originally specified with the same part number. Other Original Line cylinders with identical 1″ bore and 1″ stroke may be interchangeable depending on mounting style and port configuration—consult Bimba distributor documentation or the OEM specification sheet.
Works With
- Bimba P4 and P3 pneumatic control valve systems
- Standard 24 VDC solenoid valves
- Proportional flow control and pressure regulation
- NFPA-compatible mounting plates and manifolds
- Air preparation units (filters, regulators, lubricators)
