Overview
The Bimba 094-DX pneumatic cylinder is a double-acting original line air cylinder built for dependable operation in hydraulic and pneumatic systems. This model delivers consistent performance with standard mounting flexibility and robust construction suitable for harsh industrial environments. With its permanent grease lubrication, the 094-DX requires minimal maintenance while maintaining reliable cycle life.
Key Features
- Double-acting design for both extend and retract stroke capability
- 1-1/16″ bore with 4″ stroke configuration
- Permanent grease lubrication—no additional lubrication required during service
- Double end rod mount with universal mounting compatibility
- NPT threaded pneumatic ports for standard system integration
- Blue and Improved design provides extended cylinder life
Technical Specifications
The 094-DX cylinder features standard industrial pneumatic ports and rod configurations. Double-acting operation allows both forward and reverse movements controlled by supply and exhaust air. Port connections accommodate 1/8″ NPT fittings on both ends, with rod threads at 5/16-24 UNF-2A and mounting nuts sized at 5/8-18 for secure installation. Weight is approximately 0.60 lbs.
Typical Applications
- Assembly line automation and material handling
- Clamping and positioning fixtures
- Packaging machinery and equipment
- Industrial processing and manufacturing systems
- Plant maintenance and system upgrades
- Equipment rebuilds and retrofit projects
Compatibility & Replacements
Compatible With
- Standard pneumatic systems operating at 250 PSI maximum
- Industrial automation platforms with double-acting cylinder mounts
- Equipment using 1/8″ NPT pneumatic port connections
- Bimba Original Line controller networks and manifolds
Replaces / Drop-In Replacement For
- Earlier Bimba 094-D models (non-stainless)
- Other 1-1/16″ bore, 4″ stroke double-acting pneumatic cylinders with equivalent port configurations
Works With
- Pneumatic valve manifolds with 1/8″ NPT porting
- PLC-controlled pneumatic systems
- Compressed air distribution networks (typically 80–250 PSI operating range)
- Bimba and competitive original line cylinder mounting accessories
