Overview
The Allen-Bradley 800H-1HZ4R is an industrial-grade push button enclosure designed for the most demanding control environments. This Type 4/4X/13 rated enclosure features Rosite glass polyester construction, providing superior durability, corrosion resistance, and impact protection in wet, dusty, or chemically harsh locations. The single 30 mm push button hole with 1¾” hub accommodates standard Allen-Bradley 30 mm pushbutton operators and pilot lights, making it an essential component in control panel assemblies, machine automation, and process control systems.
Key Features
- NEMA 4/4X/13 rating for wet, dusty, and corrosive environments
- Rosite glass polyester construction for superior chemical and corrosion resistance
- Single 30 mm push button hole with 1¾ inch (50 mm) hub diameter
- Compact dimensions: 110 mm H × 80 mm W × 50 mm D
- UL, CSA, CUL, CE, and marine certification for global compliance
- Quick installation with standard mounting hardware
Technical Specifications
The following specifications define the 800H-1HZ4R enclosure performance and physical characteristics:
- Enclosure Type: Push Button Enclosure (NEMA 4/4X/13)
- Material: Rosite Glass Polyester
- Device Holes: 1 hole (30 mm)
- Hub Size: 1¾ inch diameter
- Height: 110 mm (4.33 inches)
- Width: 80 mm (3.15 inches)
- Depth: 50 mm (1.97 inches)
- Weight: 2.05 lb (0.93 kg)
- Certifications: UL, CSA, CUL, CE, KC, MARINE
- Compatible Operators: Allen-Bradley 800H 30 mm pushbuttons and pilot lights
Typical Applications
The 800H-1HZ4R enclosure is widely used in:
- Industrial machine control panels and operator stations
- Water treatment and wastewater systems
- Food and beverage processing facilities
- Chemical manufacturing and plant control
- Automotive assembly and material handling equipment
- Outdoor and marine environments requiring corrosion resistance
- Pharmaceutical manufacturing and packaging systems
Compatibility & Replacements
Compatible With
- Allen-Bradley 800H Series 30 mm pushbutton operators
- Allen-Bradley 800H pilot lights and indicator heads
- Standard industrial control panel designs and mounting rails
- Machine automation and PLC-based control systems
- NEMA 4/4X/13 rated enclosure applications
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. The 800H-1HZ4R is the current production enclosure for single 30 mm pushbutton configurations in the 800H series.
Works With
- Allen-Bradley 800H pushbutton operator series (contact blocks, contact modules)
- Standard conduit and electrical box mounting infrastructure
- Rockwell Automation control and safety systems
- Industrial automation networks using standard pushbutton input modules
