Overview
The Allen-Bradley 800FP-LF4PN3RX01 is a 22mm momentary push button offering integrated LED illumination with a red plastic operator and white legend insert. This pilot device combines flush design for panel-mount applications with robust electrical performance, making it ideal for industrial machinery, process control, and emergency signaling circuits. The unit supports both incandescent and LED lamp options at 24V AC/DC supply voltage.
Key Features
- Integrated LED module with 24V AC/DC supply compatibility
- Red illuminated operator with white insert for operator visibility
- 22mm flush plastic operator (Type 4/4X/13 rated)
- Momentary action with standard screw contact block termination
- Chemical-resistant engineering-grade thermoplastic construction
- IP65/IP66 environmental rating for indoor/outdoor and wet locations
Technical Specifications
- Operator Size: 22mm diameter
- Action Type: Momentary (non-maintained)
- Illumination: Integrated LED module
- Supply Voltage: 24V AC/DC (selectable incandescent or LED)
- Operator Material: Engineering-grade thermoplastic
- Operator Design: Flush
- Operator Color: Red knob with white insert
- Contact Configuration: Standard blocks available
- Mounting: Plastic latch mount
- Termination: Screw contact block
- Environmental Rating: IP65/IP66, Type 4/4X/13
- Operating Temperature: -25°C to +70°C
Typical Applications
- Start/Stop control buttons in manufacturing and assembly lines
- Operator interface buttons in process control systems
- Panel-mounted pilot devices in electrical enclosures
- Emergency signaling and acknowledgment circuits
- Machine tool control stations requiring visual feedback
Compatibility & Replacements
The 800FP-LF4PN3RX01 is part of the Allen-Bradley 800F family of modular pushbutton and selector switch operators. It integrates with standard 800F contact blocks and mounting frames, enabling flexible panel design. Alternative 22mm operators within the 800F range include non-illuminated variants (800FP-LF4PN3), different colors, and extended or 2-color legend options. For metal housing applications, the 800FM series offers Type 4/13 rated die-cast alternatives. Consult the Rockwell Automation technical documentation or contact an authorized distributor for detailed substitution matrices and application support.
