Overview
The Allen-Bradley 104-C23D22 is a 23A, 3-pole IEC reversing contactor engineered for motor control and industrial automation. Operating at 110V 50Hz / 120V 60Hz AC coil voltage, this contactor delivers space-saving performance in demanding control applications. With a 600V maximum voltage rating and auxiliary contact configuration, the 104-C23D22 provides dependable electromagnetic switching for reversing motors and multi-directional motor applications.
Key Features
- 23A rated capacity at 400 VAC-3 pole operation
- IEC standard design with compact footprint
- One normally open (NO) and one normally closed (NC) auxiliary contact
- Line side coil termination for standard control wiring
- Screw terminals for secure motor load connections
- DIN rail mounting compatible (35mm)
- Low power consumption design
Technical Specifications
This IEC reversing contactor is rated for 23A at 400 VAC in 3-pole configuration and 32A at 400 VAC in single-phase operation. The 110V 50Hz / 120V 60Hz AC coil ensures compatibility with standard international and North American control voltages. Motor load ratings include 5HP @ 200V, 7.5HP @ 230V, 15HP @ 460V, and 15HP @ 575V. The contactor features screw terminals and line-side coil connection with auxiliary contact blocks mounted to the unit base.
Typical Applications
- Reversing duty AC motor control systems
- Pump and compressor motor starter circuits
- Conveyor system directional control
- Industrial machinery forward/reverse switching
- HVAC and fan motor applications
- General motor protection and control circuits
Compatibility & Replacements
Compatible With
- Allen-Bradley Bulletin 104-C series motor control systems
- IEC standard 3-phase motor control circuits
- 110V/120V AC control voltage systems
- Standard 35mm DIN rail mounting configurations
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering for specific replacement model numbers and retrofit applications.
