Overview
Catalog item 1606-XLP90E-2 from Rockwell Automation® is a 90 W, 24 V DC two-phase power supply. It has no special function and it is compact family. This Allen-Bradley SMPS is powered with 380 to 480 Volts AC input voltage. With regular loading, the device generates a rated power output of 100 Watts. The compact size of the 1606-XLP90E-2 power supply makes it possible to save panel space and costs.
Key Features
- The Allen-Bradley 1606-XLP90E-2 power supply is a switched-mode power supply (SMPS) that provides improved efficiency over traditional linear power supplies.
- The device has an 89% efficiency rating.
- The Allen-Bradley 1606-XLP90E-2 power supply comes with overload and short circuit protection.
- The device can be mounted by using a DIN rail mount with a height of 7.5 to 15 millimeters.
- The 1606-XLP90E-2 power supply has been marked with the CE standard and it also meets the EMC guidelines.
Technical Specifications
The 1606-XLP90E-2 delivers current at the output maintained at 4.2 Amps with an adjustable output voltage and operates across a wide industrial temperature range for reliable performance.
- 380 to 480 Volts AC input voltage
- Output: 24–28 VDC
- 4.2 A output current
- 100 Watts rated power output
- 89% efficiency
- Dimensions: 73 x 75 x 103 millimeters; Weight: 360 grams
- Ambient temperature: -10 to 70 degrees Celsius
- DIN rail mount (7.5–15 mm height)
- Screw/Spring Clamp Terminals
Certifications & Standards
Standards: C-TICK, CE, CSA, CUL, GOST, KC, MARINE, UL ensure compliance with global safety requirements and industrial application standards.
Typical Applications
- Industrial automation and process control systems
- PLC and controller power backup
- Safety-critical control circuits
- Suitable for applications in industrial environments as well as in residential environments
- DIN rail cabinet-mounted installations requiring compact footprint
Compatibility & Replacements
The 1606-XLP90E-2 is part of the Allen-Bradley 1606 XLP series of compact switching mode power supplies. Allen-Bradley® Bulletin 1606 power supplies are compact and designed to accept a wide range of AC and DC voltages. And they meet most worldwide single- and three-phase requirements and all global safety standards. For alternative ratings or configurations, consult the Rockwell Automation 1606 XLP product line documentation. This unit is suitable as a direct replacement within equivalent specifications.
