Overview
The Cognex ACC-24I is a compact switching mode power supply engineered for vision system applications and industrial control environments. It delivers stable 24VDC output with 2A capacity, accommodating both AC and DC input power sources. Designed for DIN rail mounting, this unit integrates seamlessly into standard control enclosures, providing reliable power for Cognex In-Sight and DataMan vision cameras, as well as compatible automation devices.
Key Features
- Wide input voltage range: 85–264VAC (120VAC / 220VAC / 240VAC nominal) and 90–350VDC (110VDC / 220VDC nominal)
- Regulated output: 22.5–28.5VDC output with current limiting protection
- Compact DIN rail form factor: DIN rail mounting for space-efficient panel installation
- Industrial protection rating: IP20 degree of protection
- Wide operating temperature range: –25°C to +70°C ambient air temperature for operation
- Multiple safety certifications: UL, cULus, EN61558-2-17, EN60950, EN61000-3-2, EN50178, VDE0805, VDE0160 compliant
Technical Specifications
- Input Voltage (AC): 85–264VAC, 50/60Hz
- Input Voltage (DC): 90–350VDC
- Output Voltage: 22.5–28.5VDC
- Output Current: 2A nominal
- Mounting: DIN Rail
- Protection Degree: IP20
- Operating Temperature: –25°C to +70°C
- Storage Temperature: –40°C to +85°C
- Weight: 1.0 lbs
- Certifications: UL, cULus, EN61558-2-17, EN60950
Typical Applications
The ACC-24I power supply is ideal for powering Cognex vision inspection systems in manufacturing, quality control, and material handling environments. It supports:
- Cognex In-Sight 2000 and In-Sight 9000 series cameras
- Cognex DataMan barcode readers and code readers
- Industrial automation control cabinets requiring regulated 24VDC power
- Multi-camera vision system installations with centralized power distribution
- Integration into existing machine control systems and PLC-based applications
Compatibility & Replacements
Compatible With
- In-Sight 2000 series cameras
- In-Sight 9000 series cameras
- DataMan barcode and vision systems
- Standard industrial 24VDC powered sensors and actuators
- DIN rail mounted control enclosure infrastructure
Replaces / Drop-In Replacement For
- ACC-24V-NA (legacy model)
Works With
- Cognex vision system software and configuration tools
- Industrial automation networks supporting 24VDC powered devices
- Standard control cabinet architectures (UL 508A, CSA C22.2)
- Both AC and DC primary power distribution systems
