Overview
The Allen-Bradley 889D-F4EC-15 cordset provides a pre-assembled, quick-disconnect solution for DC Micro (M12) sensor connections. The 15-meter length accommodates longer cable runs, while the braided shield provides electromagnetic interference (EMI) protection in electrically noisy environments. With industry-standard IEC color coding and a female straight connector, this cordset integrates seamlessly into Allen-Bradley and third-party automation systems.
Key Features
- 4-pin female straight M12 DC Micro connector
- 15-meter pre-assembled cordset with no field attachment required
- Shielded construction (braided shield) for EMI noise rejection
- Yellow PVC cable with IEC standard color coding for fast identification
- Series B connector compatibility for Allen-Bradley discrete I/O and sensor applications
- Drop-in replacement for OEM and aftermarket automation systems
Technical Specifications
- Connector Type: M12 DC Micro (4-pin)
- Pin Configuration: Female straight
- Cable Length: 15 meters (49.2 feet)
- Cable Material: PVC
- Shielding: Braided shield
- Cable Color: Yellow
- Wire Gauge: 22 AWG
- Color Coding: IEC standard
- Connector End: No connector (one end bare leads)
- Series: 889D, Series B
- Operating Temperature: -10°C to +60°C (typical for PVC insulation)
- Voltage Rating: 60 VDC (typical M12 DC Micro)
- Current Rating: 4 A per pin (standard M12 rating)
- Certification: IEC 61076-2-109 compliant
Typical Applications
- Proximity sensors and inductive switches
- Photoelectric sensor connections
- Discrete DC I/O modules with M12 inputs
- Industrial control system sensor harnesses
- Factory automation and machinery control
- OEM equipment integration
Compatibility & Replacements
The 889D-F4EC-15 is a direct fit for Allen-Bradley and compatible with any M12 4-pin female straight DC Micro application. The shielded variant is preferred in high-noise industrial environments; unshielded alternatives (889D-F4AC series) are available for standard applications. Verify connector gender and pin count before substitution. Contact your distributor for equivalent products from Siemens (M12 A-coded), Phoenix Contact, or Molex when cross-platform compatibility is required.
