Overview
The Allen-Bradley 871A-TS5-DM1 is a field-attachable Micro 5 pin straight male connector designed for industrial sensor and automation applications. This NEMA 6-rated terminal chamber provides reliable connectivity in proximity sensor installations and other control system applications requiring secure, sealed connections in harsh industrial environments.
Key Features
- 5-pin micro connector in straight male configuration
- NEMA 6 rated for moisture and dust protection
- Field-attachable design for on-site cable termination
- Rated 4 amperes maximum current
- Cable range: 6-8mm (PG9 thread)
- Compact terminal chamber design for tight installations
Technical Specifications
- Pin Count: 5
- Connector Type: Straight Male
- Current Rating: 4 Amperes
- NEMA Rating: NEMA 6 (dusttight, watertight)
- Cable Size Range: 6-8 mm (0.24-0.31 in.)
- Cable Thread: PG9
- Wire Gauge: 18 AWG
- Weight: 25.0 g
- Manufacturer: Allen-Bradley (Rockwell Automation)
- Part Number: 871A-TS5-DM1
Typical Applications
- Proximity sensor connections in automated assembly lines
- Industrial control systems requiring sealed connectors
- Material handling equipment sensor integration
- Manufacturing machinery with outdoor or wet-environment installations
- Harsh environment sensor terminals
Compatibility & Replacements
Compatible With
- Allen-Bradley proximity sensors with 5-pin micro connectors
- Industrial automation control systems using Micro 5 pin inputs
- Rockwell Automation integrated sensor networks
- Standard 18 AWG field-attachable cable systems
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. The 871A-TS5-DM1 is a specific Micro 5 pin male connector configuration; equivalent models may exist in other product lines but should be cross-referenced with your application requirements.
Works With
- Allen-Bradley sensor product lines
- Industrial Ethernet proximity sensing systems
- Standard PLC and motion control platforms using discrete sensor inputs
- Field-attachable cable assemblies (18 AWG, 6-8mm cable)
