Overview
The Allen-Bradley 800S push button control station cover is a standard-duty replacement enclosure designed for three-button motor control applications. Part of the trusted 800S family, this cover assembly features a Fast/Slow/Stop button configuration and NEMA Type 1 rating, making it ideal for indoor industrial environments where operators need intuitive speed and directional control of AC motors.
Key Features
- Momentary contact push button operation for safe, spring-return control
- Three-button configuration: Fast, Slow, and Stop for intuitive motor control
- NEMA Type 1 enclosure rating for indoor use in electrical cabinets
- Surface-mount design with flexible horizontal or vertical mounting options
- Completely assembled and ready for field installation
- UL, CSA, and KC certified for safety and reliability
Technical Specifications
- Contact Rating: 5 A at 600 VAC
- Enclosure Type: NEMA Type 1
- Button Configuration: Momentary Contact – Type 1
- Mounting: Surface mount
- Button Legend: Fast/Slow/Stop
- Standards: UL, CSA, KC certified
- Manufacturer: Allen-Bradley (Rockwell Automation)
Typical Applications
The 800S push button control station cover is commonly used in:
- AC motor speed and direction control in machine tools and industrial equipment
- Conveyor system operation and speed modulation
- Pump and fan motor control in HVAC and process applications
- Material handling equipment requiring operator-initiated start/stop functions
- Electrical cabinet-mounted operator interfaces for distributed automation systems
Compatibility & Replacements
The Allen-Bradley 800S series offers several three-button configurations. This cover is compatible with standard 800S push button station bases and supports common three-button legend combinations including Open/Close/Stop (800S-3SD), Fast/Slow/Stop (800S-3SF), and Forward/Reverse/Stop (800S-3SA). Always verify the base model and contact block configuration before installation to ensure proper electrical integration with your control circuit.
