Overview
The Allen-Bradley 800H-R2 is a 30.5mm non-illuminated push button operator with a booted head configuration. Built to operate in Type 4/4X/13 rated enclosures, this pilot device delivers proven reliability in industrial control applications. Supplied as an operator only without contact blocks, it integrates seamlessly into existing 800H station infrastructure.
Key Features
- Momentary Contact Operation: Standard momentary action for on-demand control without latching
- Booted Head Design: Protective rubber boot prevents moisture and debris ingress
- Non-Illuminated: Simple, durable plastic construction without lamp requirements
- Type 4/4X/13 Rating: Suitable for wet, corrosive, and sealed indoor environments
- 30.5mm Mounting Hole: Direct compatibility with standard 800H enclosure stations
- Finger-Safe: Compliant terminals with no protruding guards needed
Technical Specifications
- Operator Type: Booted head, non-illuminated
- Enclosure Rating: Type 4/4X/13 (NEMA 4/4X/13)
- Size: 30mm (30.5mm hole mounting)
- Contact Configuration: No contacts on operator (field-configurable)
- Button Cap Color: Black
- Material: Thermoplastic polyester resin with zinc alloy bushing
- Mounting: Panel-mount through 30.5mm hole
- Weight: 0.16 lbs (73g)
- Operating Temperature: -25°C to +60°C (depending on enclosure environment)
Typical Applications
- Manufacturing machinery start/stop controls
- Assembly line operator interfaces
- Pump and motor control circuits
- HVAC equipment switching
- Conveyance system activation
- Panel-mounted momentary-contact circuits requiring non-illuminated actuation
Compatibility & Replacements
Compatible With
- 800H station bases and enclosure covers
- Bulletin 800H Type 4/4X/13 component systems
- Standard 800-series shallow contact blocks (sold separately)
- Industrial control panels rated NEMA 4/4X/13
- 30mm pilot device mounting holes
Replaces / Drop-In Replacement For
- Original equipment 800H-R2 operators requiring operator-only replacement
- Worn or damaged booted-head push button operators in 800H stations
- Verify part compatibility with your system integrator or Rockwell Automation distributor before ordering replacement units
Works With
- 800H Bulletin contact block kits (standard, sealed switch, or logic reed)
- Rockwell Automation 30mm station covers and accessories
- IEC 269-1/269-2 fused control circuits
- Direct drive positive-opening circuits with NC contact blocks
- Traditional hardwired control relay logic systems
