Overview
The Allen-Bradley 800H-PRB16R is a 30mm momentary push button switch from the 800H series, featuring an extended head design without guards and transformer-based 120V AC 50/60 Hz incandescent illumination with a red lens. This rugged control device is manufactured by Rockwell Automation and rated for Type 4/4X/13 indoor and outdoor enclosures, making it suitable for harsh industrial environments.
Key Features
- Momentary action: Spring-return contact mechanism for latching or momentary control applications
- Extended head design: Non-guarded operator provides clear visibility and accessibility
- Dual-contact configuration: 1 NO (normally open) and 1 NC (normally closed) standard contacts for flexible circuit control
- Incandescent illumination: Lamp voltage rated 120 VAC at 50/60 Hz with transformer integration
- Red lens: High-visibility indicator for status signaling
- Multi-standard certification: Certified CCC, CE, CSA, CUL, KC, MARINE, UL for global deployment
Technical Specifications
- Part Number: 800H-PRB16R
- Button Size: 30mm
- Action Type: Momentary
- Head Style: Extended Head without Guard
- Illumination Type: Incandescent with Transformer
- Lens Color: Red
- Lamp Voltage: 120 VAC 50/60 Hz
- Contact Configuration: 1 NO / 1 NC Standard
- Guard Type: None (Open Terminals)
- Enclosure Rating: Type 4/4X/13
- Certifications: UL, CSA, CE, CUL, CCC, KC, MARINE
- Condition: New in Box
- Compatible Series: 800H PB (Pilot Devices)
Typical Applications
The 800H-PRB16R is engineered for critical operator interface tasks in industrial automation and process control:
- Panel-mounted start/stop push buttons in electrical enclosures and control stations
- Manual control and emergency stop circuits where visual feedback is required
- Outdoor and wet-environment applications requiring sealed construction and high IP rating
- Type 4/4X/13 rated enclosures for food processing, chemical, pharmaceutical, and marine facilities
- Status indication and operator feedback in machine and process monitoring systems
Compatibility & Replacements
Compatible With
- Rockwell Automation 800H Series control stations and enclosures
- Standard 120V AC industrial transformer circuits (50/60 Hz)
- NEMA/IEC Type 4, 4X, and 13 rated electrical enclosures
- Emergency stop and manual control circuits (non-safety-rated)
- Allen-Bradley 800 Series pilot light and selector switch assemblies
Replaces / Drop-In Replacement For
The 800H-PRB16R is the complete assembly for Bulletin 800H momentary push button applications. For specific legacy model replacements, consult with your Allen-Bradley distributor or Rockwell Automation to verify compatibility with your existing station design.
Works With
- 800H Series contact blocks and assemblies
- Standard industrial 120V AC control transformers
- NEMA 4/4X enclosure mounting systems
- Legacy and modern Allen-Bradley control panel designs
- Manual operator interface circuits (not PLC-integrated)
