Overview
The Allen-Bradley 800F-1YM3 is a factory-assembled emergency stop enclosure designed for critical machine safety control. This 22mm station combines a yellow plastic 1-hole enclosure with a secure 40mm twist-to-release operator that prevents accidental emergency stop release. Compliant with global safety standards, it is ideal for OEM machinery, process control cabinets, and retrofit installations.
Key Features
- Fully assembled 22mm E-Stop station—ready for mounting without component assembly
- 40mm twist-to-release operator—provides positive reset safety feedback
- 2 normally-closed (NC) contacts—dual circuit redundancy for safety systems
- Yellow plastic 1-hole enclosure—IP66 rated for sealed, washdown-resistant installations
- Metric conduit knockouts—field-wiring simplicity for metric cable entries
- Non-illuminated design—suitable for applications without status indicator requirements
Technical Specifications
- Part Number: 800F-1YM3
- Size: 22mm
- Operator Type: 40mm Twist-to-Release
- Contact Configuration: 2 NC (Normally Closed)
- Enclosure Material: Plastic
- Mounting Type: Latch or Base
- Number of Holes: 1
- Conduit Entry: Metric Knockouts
- Color: Yellow
- IP Rating: IP66
- Standards: UL, CSA, CUL, KC, MARINE
- Weight: 0.68 lb (0.31 kg)
- UPC: 78118047235
Typical Applications
- Emergency stop circuits in manufacturing equipment and production lines
- Machine safety control panels and operator stations
- Food processing, chemical, and washdown-intensive environments
- OEM machinery with integrated safety systems
- Retrofit installations requiring sealed, sealed enclosure protection
Compatibility & Replacements
The 800F-1YM3 is part of the Rockwell Automation 800F push-button series, which operates as a standard component in Allen-Bradley industrial control systems. This unit is a direct replacement for existing 22mm emergency stop assemblies and integrates with all 800F-series contact blocks and operator options. No special adapters or modifications are required for standard 22mm panel cutout installations. For system integration with PLC/safety relay modules, consult the relevant I/O configuration documentation.
