Overview
The Allen-Bradley 1585D-M4DC-SH is a field-attachable M12 insulation displacement connector designed for Ethernet connectivity in harsh industrial environments. This 4-pin, straight male, shielded M12 IDC is designed for reliable field installation without the need for hand tools. The robust zinc die-cast body enhances shielding capabilities, making it suitable for applications in harsh environments.
Key Features
- Tool-free field installation capability
- IP67 rating ensures protection against dust and water ingress
- Zinc die-cast housing for superior EMI shielding
- Supports 24 to 22 AWG wire sizes
- Over-molded housing suitable for harsh industrial environments with extreme vibration, shock, chemicals, and temperature
- Operating temperature range of -25 to +85°C (-13 to +185°F)
Technical Specifications
Ethernet Media, Micro Style QD (D-code QD), 4-pins, 6-7mm (0.22–0.28″), 22AWG connector with flying leads.
- Configuration: 4-pin, straight male
- Voltage rating: 32V; Current rating: 4A
- Wire size: 24 to 22 AWG
- Operating temperature: -25 to +85°C
- IP rating: IP67
- Connector type: M12 D-code
- Housing: Shielded, zinc die-cast
Typical Applications
Bulletin 1585 Ethernet Cable Spools provide reliable network connections in harsh surroundings. Common applications include:
- Industrial automation control systems
- EtherNet/IP networked I/O modules and drives
- Harsh-environment plant floor connectivity
- Mobile machinery and outdoor installations
- Vibration-heavy manufacturing environments
Compatibility & Replacements
Compatible With
- Allen-Bradley 1585 Ethernet cable assemblies
- EtherNet/IP networks
- M12 D-code Ethernet devices
- Cat 5e twisted-pair Ethernet media
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. This connector is part of the Allen-Bradley 1585 Ethernet media family and may replace earlier revision connectors in the same series. Consult technical documentation for specific model compatibility.
Works With
- EtherNet/IP protocols
- Rockwell Automation control systems
- Studio 5000 / CompactLogix / ControlLogix networks
- Standard Cat 5e Ethernet cabling
- M12 D-code connector ecosystems
