Overview
The Allen-Bradley 1492-CAB010D69 is a precision-engineered prewired cable for 1769-OB16 and -OV16 digital output modules. Manufactured by Rockwell Automation, this cable eliminates custom field wiring and reduces commissioning time in critical automation systems. The factory-terminated connectors ensure proper pinout and signal integrity for CompactLogix and other Allen-Bradley digital I/O applications.
Key Features
- Factory pre-wired and tested—ready for immediate installation
- Designed specifically for 1769-OB16 and 1769-OV16 output modules
- Eliminates custom field wiring and reduces integration time
- Meets Allen-Bradley specifications for 1769 I/O modules
- New in box condition with original packaging
Technical Specifications
- Part Number: 1492-CAB010D69
- Manufacturer: Allen-Bradley (Rockwell Automation)
- Cable Length: 1.0 meter (3.28 feet)
- Condition: New in Box
- Wire Gauge: #22 AWG
- Connector Type: IFM connector (pre-terminated)
- Compatible Modules: 1769-OB16, 1769-OV16
- Product Type: Digital Cable Connection Products
Typical Applications
The 1492-CAB010D69 is widely used in manufacturing and process automation for connecting digital output modules to:
- Discrete output control systems (solenoids, motor starters, indicator lights)
- CompactLogix and Micro800 systems with 1769 I/O modules
- Machine control and factory automation panels
- Production line integration where quick deployment is critical
Compatibility & Replacements
Compatible With
- Allen-Bradley CompactLogix controllers with 1769 backplane
- 1769-OB16 (16-point discrete output module)
- 1769-OV16 (16-point discrete output module—high-speed variant)
- Studio 5000 Logix Designer programming environment
- 1769 backplane and I/O module systems
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. This cable is designed specifically for 1769-OB16 and 1769-OV16 modules; alternative part numbers may exist for other 1769 module types.
Works With
- Allen-Bradley Studio 5000 Logix Designer
- CompactLogix L18, L24, L35, and later series
- 1769 I/O module communications
- Discrete 24 VDC digital output control
