Overview
The Accudrive RG20009SAAA03 is a right angle precision servo gearhead from Cone Drive’s Accudrive product family. The Series RG is a compact right angle precision drive providing an economical solution for general automation applications. Built around the Cone Drive double-enveloping worm technology, the Accudrive Series RG is available in standard and low backlash options. This unit is designed for reliable performance in packaging, food and beverage, and broader industrial automation environments.
Key Features
- Double-Enveloping Worm Gear Technology: Features true double-enveloping worm gear technology in compact right angle drives, providing high torque density.
- Factory-Filled Synthetic Lubricant: The RG is factory-filled with synthetic lubricant and quality-built in standard and low backlash options with hollow shaft to provide complete flexibility.
- High Torque Output: Output torque up to 7,800 lb.in. (880 Nm)
- Multiple Output Configurations: Inch or metric, solid (single or double extended), hollow, shrink disc, mounting flange options available
- Sealed Design: IP 65 rating
Technical Specifications
Specific technical data for model RG20009SAAA03 should be verified with the manufacturer or authorized distributor. General series specifications:
- Gearbox Type: Right Angle Worm Drive
- Manufacturer: Cone Drive Operations, Inc.
- Product Family: Accudrive Series RG
- Backlash Options: Standard, Low Backlash
- Shaft Options: Solid (single or double extension), hollow, shrink disc
- Lubrication: Factory-filled synthetic
- Protection Rating: IP 65
Typical Applications
The Accudrive product family offers precision motion control solutions for applications like packaging, food and beverage, and automation. The RG series is commonly used in:
- Packaging machinery positioning and indexing
- Food and beverage processing equipment
- General industrial automation systems
- Servo-driven conveyors and transfer systems
- Positioning tables and lifting mechanisms
Compatibility & Replacements
Compatible With
- Standard servo motors with compatible flange mounting
- NEMA-frame motor adapters (when specified)
- IEC-frame motor adapters (when specified)
- Right angle mounting configurations (shaft and flange mount)
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. Accudrive RG series units may be compatible with other Cone Drive right angle gearheads of the same size and ratio specifications, but model-specific verification is required.
Works With
- Servo motor control systems
- Motion control PLCs and drives
- Industrial automation platforms
- Precision positioning applications
