Overview
The Allen-Bradley 800T-PC416 Series N is a professional-grade 4-unit cluster pilot light assembly designed for industrial control panels and machinery. This model features a built-in transformer, incandescent lamps, and multiple color lens options to provide clear visual indication in demanding manufacturing and automation environments.
Key Features
- 4-unit cluster configuration allows simultaneous indication of multiple states or functions
- Incandescent lamp type with proven reliability in industrial settings
- Built-in transformer simplifies installation and reduces auxiliary components
- Multi-color lens options (red, green, blue, clear) for visual clarity
- 30 mm unit size fits standard NEMA-rated control enclosures
- Transformer-type construction provides 120VAC operation from standard industrial power
Technical Specifications
- Input Voltage: 120 VAC, 50/60 Hz
- Power Consumption: 9.2W
- Lamp Type: Incandescent
- Unit Configuration: 4-Unit Cluster
- Unit Size: 30 mm (30.5 mm diameter)
- Enclosure Rating: NEMA 4, 13
- Operating Temperature: -40°F to 131°F (-40°C to 55°C)
- Storage Temperature: -40°F to 185°F (-40°C to 85°C)
- Available Lens Colors: Red, Green, Blue, Clear
- Construction: Metal base with transformer
- Series: N
Typical Applications
- Machine tool control panels and operator stations
- Manufacturing equipment status indication
- Industrial motor control centers and switchgear
- Process automation and assembly line feedback
- HVAC and building automation systems
- Pump and compressor control panels
Compatibility & Replacements
Compatible With
- Standard NEMA 4/13 industrial control enclosures
- Rockwell Automation industrial control systems
- Equipment requiring 120VAC pilot light indication
- Panel-mount 30mm IEC-standard mounting holes
Replaces / Drop-In Replacement For
- Verify compatibility with your system integrator before ordering. Consult original equipment specifications to confirm interchangeability with legacy models.
Works With
- Allen-Bradley ControlLogix and CompactLogix controllers
- Standard 120VAC industrial power supplies
- PLC-based automation systems requiring visual status indication
- Manual control stations and operator interfaces
