Overview
The Allen-Bradley 800T-FXQ24AA1 is a 30mm illuminated pushbutton operator from the Series T line. This red-colored unit is rated for 24V AC/DC power supply and serves as an essential component in industrial automation control cabinets, machinery interfaces, and process control panels.
Key Features
- 30mm modular design compatible with Allen-Bradley 800T series enclosures and frameworks
- Red illuminated pushbutton operator for high-visibility status indication
- 24V AC/DC rated for standard control voltage applications
- Durable construction rated for Type 4/13 indoor industrial environments
- Modular architecture allows stacking with additional pushbutton units and contact blocks
- Finger-safe terminals for safe panel integration
Technical Specifications
- Rated Voltage: 24V AC/DC
- Operator Type: Illuminated Pushbutton (Red)
- Button Size: 30mm
- Series: 800T (Series T)
- Enclosure Rating: Type 4/13 (Indoor)
- Operating Temperature: -4 to 140°F (-20 to 60°C) without moisture
- Contact Finger-Safe: Yes
- Mechanical Life: 150,000+ operations (with compatible contact blocks)
Typical Applications
The 800T-FXQ24AA1 is widely deployed in manufacturing environments including:
- Machine start/stop control stations
- Emergency stop (E-stop) assemblies
- Production equipment operator interfaces
- Process automation and material handling systems
- HVAC and building automation control panels
- Conveyors, presses, and motor control stations
Compatibility & Replacements
Compatible With
- Allen-Bradley 800T series 30mm push button stations
- Type 4/13 industrial control enclosures
- All standard 800T contact block assemblies and lamp modules
- Modular pilot light and selector switch combinations
- 24V AC/DC control power supplies and transformers
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. The 800T-FXQ24AA1 is part of an active product family with similar models available through Allen-Bradley distributors.
Works With
- Allen-Bradley control relays and contactors
- Rockwell Automation PLC input modules
- 24V AC/DC pilot duty circuits
- Standard industrial control wiring practices (per NEMA standards)
- Modular enclosure frameworks and DIN rail mounting systems
