Overview
The Allen-Bradley 800H-N5A is a protective push button boot engineered for non-illuminated 30 mm push buttons in the 800H series. This red boot accessory delivers dependable protection in demanding industrial environments, featuring chlorosulfonated polyethylene construction with a stainless steel insert for corrosion resistance. The 800H-N5A integrates seamlessly with Allen-Bradley 30 mm operators and fits standard 30 mm mounting holes.
Key Features
- Red protective boot for 30 mm non-illuminated pushbuttons
- Chlorosulfonated polyethylene (CPE) material resists moisture and corrosive environments
- Stainless steel insert provides durability and long service life
- NEMA 4/4X/13 Type rating for watertight, oiltight, and corrosion-resistant enclosures
- Compatible with Allen-Bradley 800H and 800T operator platforms
- Supports industrial control, machinery, and automation applications
Technical Specifications
- Part Number: 800H-N5A
- Color: Red
- Size: 30 mm diameter
- Material: Chlorosulfonated Polyethylene (CPE)
- Insert Material: Stainless Steel
- Series: 800H Series B
- Application Type: Protective boot accessory
- Compatible Button Size: 30 mm non-illuminated pushbuttons
- Operating Temperature Range: -13°F to 104°F (-25°C to +40°C)
- NEMA Rating: Type 4/4X/13 (watertight, oiltight, corrosion resistant)
- Mounting Hole Diameter: 30 mm standard
Typical Applications
- Factory floor control stations and emergency stop (E-stop) assemblies
- Food and beverage processing equipment requiring washdown protection
- Chemical and pharmaceutical manufacturing with corrosive atmospheres
- Wastewater treatment and marine applications
- Outdoor industrial enclosures and Type 3R/4X environments
- Heavy machinery and press control stations
Compatibility & Replacements
Compatible With
- Allen-Bradley 800H series 30 mm push button operators
- Allen-Bradley 800T series 30 mm push buttons (with 800H enclosures)
- Standard 30 mm push button mounting hole configurations
- NEMA 4/4X/13 stainless steel and fiberglass enclosures
- Industrial control stations and operator stations
- Type 4X watertight and oiltight panel enclosures
Replaces / Drop-In Replacement For
- Previous Allen-Bradley 800H push button boot models (exact cross-reference subject to application; verify with system integrator)
- Other 30 mm CPE boot accessories requiring stainless steel inserts
Works With
- Allen-Bradley Studio 5000 and FactoryTalk control software platforms
- Non-illuminated 30 mm push button blocks and contact configurations
- NEMA 4/4X/13 industrial control enclosure assemblies
- Rockwell Automation integrated automation and control architectures
