Overview
The Allen-Bradley 700-HHF62Z24 is a general-purpose power relay from the H-Series family, engineered for industrial automation and process control applications. This flange-mounted relay combines rugged construction with reliable switching performance, making it a proven choice for OEMs and system integrators across manufacturing, HVAC, and utility applications.
Key Features
- 2-Pole Double-Throw (DPDT) Configuration — Dual independent switching circuits for versatile control logic and signal routing
- 25 Amp Contact Rating — Rated for 25A @ 120V AC or lower DC ratings; supports general industrial loads
- 24V DC Coil Voltage — Standard low-voltage control supply compatible with most cabinet power sources
- 10 Million Mechanical Life — Proven endurance for high-cycle applications, reducing maintenance costs
- Flange Mount with Blade Terminals — Quick-connect design for DIN rail or cabinet panel mounting
- Open-Style Construction — Accessible for inspection and testing in field service
Technical Specifications
- Contact Configuration: DPDT (2-pole, 2-throw)
- Coil Voltage: 24V DC
- Contact Rating: 25 A
- Contact Material: Silver Cadmium Oxide
- Mechanical Life: 10,000,000 operations
- Operating Temperature: –30 to +65 °C (–22 to +149 °F)
- Mounting Style: Flange Mount
- Terminal Style: Blade-style (8 terminals)
- Power Rating: 1.4 W
- Weight: 0.20 lbs
- Certifications: CE, CUL, KC, UL
Typical Applications
- General-purpose motor starters and contactors
- Lighting and HVAC control circuits
- Pump and fan interlocking logic
- Alarm and shutdown signal routing
- Industrial panel-mount switchgear
- Process control and automation cabinets
Compatibility & Replacements
Compatible With
- 24V DC control circuits in industrial control panels
- DIN rail and surface-mounted enclosures
- General-purpose relay sockets and holders
- Standard automation cabinets (Siemens, Schneider, ABB, GE, Omron)
- Blade-terminal connector blocks and terminal strips
Replaces / Drop-In Replacement For
- Earlier revisions of 700-HHF62Z24
- Similar DPDT relays with 24V DC coil and 25A contact rating from alternative brands (verify terminal compatibility)
Works With
- 24V DC power supplies and UPS systems
- Standard industrial control logic (hardwired, ladder logic, PLC discrete outputs)
- Relay sockets, terminal blocks, and DIN rail accessories
- No software or firmware required — passive switching device
