Overview
The Allen-Bradley 1492-CJD6-5 terminal block jumper is a 5-pole screw-center accessory engineered for modular connection and expansion of 1492 series terminal blocks. Built to industrial specifications, this jumper facilitates rapid wiring changes and simplifies circuit reconfiguration in control panels and machinery without requiring major rewiring. The gray finish and compact design integrate seamlessly into standard DIN-rail mounted automation systems.
Key Features
- 5-pole configuration for flexible circuit management
- Screw-type center design ensures secure, repeatable connections
- 6 mm center-to-center pole spacing for standardized 1492 terminal block compatibility
- Gray color standard for industrial panel aesthetics
- Compact footprint minimizes panel space consumption
- Tool-free insertion and removal for efficient maintenance
Technical Specifications
- Configuration: 5-pole jumper block
- Connection Type: Screw-type center
- Pole Spacing: 6 mm center-to-center
- Color: Gray
- Mounting: Plug-in to 1492 terminal block header
- Material: Polyamide body with brass contacts
- Operating Temperature: -25°C to +55°C
- Certifications: UL, CSA approved per 1492 series standards
Typical Applications
- Industrial control panel wiring and signal distribution
- PLC and drive I/O connection jumpers
- Machinery control circuits requiring modular expansion
- Automation system circuit reconfiguration and upgrades
- OEM equipment manufacturing and integration
Compatibility & Replacements
Compatible With
- 1492-W4 terminal block
- 1492-W4TW terminal block
- 1492 series modular terminal block systems
- Allen-Bradley automation and control systems
Replaces / Drop-In Replacement For
The 1492-CJD6-5 is the standard 5-pole screw-center jumper for 1492-W4 and W4TW terminal block headers. Verify compatibility with your specific terminal block model before ordering.
Works With
- Allen-Bradley CompactLogix controllers
- Allen-Bradley ControlLogix systems
- Rockwell Automation distributed I/O networks
- Industrial control cabinet wiring standard
