Overview
The Zero-Max C105806 is a three-way right angle gearbox that transmits power through hardened spiral bevel gears at a 2:1 transmission ratio. Designed for compact installation in confined spaces, the C105806 features a fully enclosed aluminum housing that protects internal gears from misalignment and debris contamination while enabling heat dissipation. This model is ideal for applications requiring reliable 90-degree torque redirection with minimal footprint.
Key Features
- Three-way configuration allows power input/output on any of three perpendicular axes
- Hardened spiral bevel gears ensure smooth, efficient power transmission and extended service life
- Non-magnetic stainless steel shafts resist corrosion and maintain precision alignment
- Fully enclosed anodized cast aluminum housing prevents gear contamination and provides lightweight strength
- Compact design fits tight installation spaces without sacrificing performance
- 2:1 gear ratio delivers increased torque output
Technical Specifications
- Gear Ratio: 2:1
- Configuration: Three-Way Right Angle Gearbox
- Shaft Diameter (Input/Output): 0.625 inches (5/8″) with keyway
- Shaft Length: 1.500 inches
- Overall Width: 7.000 inches
- Housing Material: Anodized Cast Aluminum
- Gears: Hardened Spiral Bevel
- Shafts: Non-magnetic Stainless Steel
- Design Type: Fully Enclosed
Typical Applications
The Zero-Max C105806 is commonly used in industrial machinery where compact right-angle power transmission is required. Applications include:
- Machine tool positioning and feed drives
- Conveyor system diverters and transfers
- Printing equipment paper path mechanisms
- Packaging machinery directional control
- Material handling equipment angle drives
- Hydraulic and pneumatic system integrations
Compatibility & Replacements
Compatible With
- Industrial automation systems requiring 90-degree torque transmission
- Motor-driven applications (electric, hydraulic, or pneumatic input)
- Machine tool control systems
- Manufacturing equipment with space constraints
Replaces / Drop-In Replacement For
The C105806 is the three-way 2:1 ratio model in Zero-Max’s Crown Gear line. Related models in the series include the C205806 (0.750″ shaft) and C805806 (1.000″ shaft) with similar configurations but larger dimensions for higher torque applications.
Works With
- Three-axis positioning and directional routing systems
- Multi-directional drive configurations
- Standard keyway couplings and shaft connections
- Industrial automation control platforms
