Overview
The Grove Gear GRL8320074.00 is a premium IRONMAN series worm gear reducer manufactured by Regal Rexnord. This 15:1 cast iron worm gear reducer provides right-angle single reduction with robust construction designed for demanding industrial automation and motion control applications. The unit features base-mount configuration and factory-filled PAG synthetic lubricant for reliable operation in continuous duty, frequent reversing, and shock-loading environments.
Key Features
- One-piece cast iron housing with single output cover design, CNC-machined for precise alignment
- 15:1 gear ratio with right-angle single reduction configuration
- Factory-filled with Mobil Glygoyle 460 PAG synthetic oil for superior cooling and splash lubrication
- FKM double-lip seals providing extended life and resistance to high temperature, abrasion, and chemicals
- Oversized high-speed bearings for frequent reversing and start/stop cycles
- Base-mount design for easy installation and secure positioning
Technical Specifications
- Manufacturer: Grove Gear / Regal Rexnord
- Part Number: GRL8320074.00
- Model Designation: GRL-BM-832-15-L-180
- Series: GRL (IRONMAN)
- Gear Type: Worm (Right Angle Single Reduction)
- Gear Ratio: 15:1
- Housing Material: Cast Iron
- Center Distance: 3.25 in
- Mounting Style: Base Mount (BM)
- Input Flange: 180TC
- Lubrication: PAG Synthetic Oil (Factory-filled)
Typical Applications
The Grove Gear GRL8320074.00 worm gear reducer is ideal for:
- Conveyors, mixers, and pumps requiring precise speed reduction
- Industrial material handling equipment with continuous duty cycles
- Packaging machinery and production line automation
- Heavy-load gearbox applications requiring shock-load resistance
- OEM and retrofit motion control systems in manufacturing facilities
Compatibility & Replacements
Compatible With
- AC and DC motors with 180TC C-Face flange coupling
- Industrial automation control systems requiring 15:1 speed reduction
- Equipment rated for 1750 rpm input speed at 1 HP through 7.5 HP range
- Base-mounted gearbox installations with standard shaft output configuration
Replaces / Drop-In Replacement For
Verify exact compatibility with your system integrator before ordering. The GRL-BM-832-15-L-180 designation indicates the 832 size frame within the GRL IRONMAN series; cross-reference with legacy Grove Gear or Regal Rexnord documentation for direct replacement models.
Works With
- Standard industrial AC motors (NEMA / IEC mounted)
- Shaft-output driven equipment and machinery
- PAG synthetic lubrication systems (Mobil Glygoyle compatible)
- Splash-lubricated bearing assemblies for extended operational life
