Overview
The Telemecanique ZCMD21C12 is a miniature limit switch body from the OsiSense XC standard range, designed for reliable operation in industrial automation and machine control applications. This 2-pole switch features 1NC+1NO contacts with Zb insulated silver-plated snap action contacts and a 5-pin M12 male connector. The fixed zamak body provides durability in harsh industrial environments while maintaining consistent contact performance.
Key Features
- Snap action contact operation for reliable switching
- Fixed zamak body construction
- 5-pin M12 male connector for electrical connection
- 2-pole 1NC+1NO contact configuration
- Production status active with recent manufacturer updates
- Miniature design for compact mounting in space-constrained applications
Technical Specifications
- Contact Configuration: 1NC + 1NO
- Contact Operation: Snap action
- Body Material: Zamak (fixed body)
- Contact Material: Silver-plated, Zb insulation
- Electrical Connection: M12 male connector, 5 pins
- Voltage Rating: 240 V AC
- Current Rating: 4 A
- Design: Miniature
- Series: OsiSense XC Standard, ZCMD
- Length: 3-1/2 inches
- RoHS Compliant: Yes
Typical Applications
The ZCMD21C12 limit switch body is suitable for:
- Machine position detection and monitoring
- Safety interlocks on industrial machinery
- Automation control systems requiring snap action switching
- Manufacturing equipment end-of-travel detection
- Process control feedback signaling
- Industrial automation in food, beverage, automotive, and material handling industries
Compatibility & Replacements
Compatible With
- Schneider XCMD series limit switches
- Telemecanique OsiSense XC range components
- Industrial automation controllers accepting 240 V AC / 4 A snap action signals
- M12 5-pin connector-equipped actuator heads
Replaces / Drop-In Replacement For
Compatible actuator heads include ZCE01, ZCE02, ZCE06, ZCE07, ZCE08, ZCE09, ZCE10, ZCE11, ZCE13, ZCE14, ZCE21, ZCE24, ZCE27, ZCE28, ZCE29, ZCE62, ZCE63, ZCE64, ZCE65, ZCE66, ZCE67, ZCEF0, ZCEF2, and ZCEG1. Verify compatibility with your specific actuator head before ordering.
Works With
- Telemecanique / Schneider Electric limit switch actuator heads (ZCE series)
- Industrial control systems using M12 5-pin connectors
- PLC inputs accepting 240 V AC snap action signals
- Safety relay circuits and interlocks
