Overview
The Yageo CFR-50JB-52-2K2 is a standard through-hole axial carbon film resistor rated at 2.2 kilohms with a 1/2W (0.5W) power dissipation and ±5% tolerance. This resistor is widely used in analog circuits, signal conditioning, and general-purpose electronics. The carbon film construction offers a proven balance of cost-effectiveness and performance, making it suitable for educational projects, prototyping, and production repair work.
Key Features
- Axial through-hole lead configuration for breadboard and PCB mounting
- Carbon film construction with helical grooved resistive layer for stability
- Standard ±5% tolerance across operating range
- Rated for 250V maximum working voltage
- Wide operating temperature range (-55°C to +155°C)
- AEC-Q200 automotive qualification ensures reliability
Technical Specifications
- Resistance Value: 2.2 kOhms (2.2 kΩ)
- Power Rating: 0.5W (1/2W)
- Tolerance: ±5%
- Composition: Carbon Film
- Lead Configuration: Axial
- Maximum Working Voltage: 250V
- Operating Temperature: -55°C to +155°C
- Temperature Coefficient: -500 to +350 ppm/°C
- Series: CFR
- Quantity per Pack: 200 units
Typical Applications
- General-purpose analog signal circuits and filters
- Biasing networks in amplifier stages
- Pull-up/pull-down resistor networks
- Educational and hobbyist electronics
- Equipment repair and component replacement
- Prototyping and breadboard development
Compatibility & Replacements
Compatible With
- All standard 1/4-inch spaced breadboards and perfboards
- Standard PCB soldering and wave-soldering equipment
- Analog signal chains and DC bias circuits
- Industrial and automotive electronics (AEC-Q200 rated)
Replaces / Drop-In Replacement For
- Yageo CFR-50JB-52-2K2 (primary part number)
- Yageo CFR-50JT-52-2K2 (alternate axial variant)
- Generic 2.2kΩ 1/2W carbon film resistors in equivalent tolerance
- Other 2.2k ohm 1/2W axial carbon film resistors with ±5% tolerance
Works With
- Standard soldering irons and wave-solder machines
- Breadboarding and prototyping systems
- Any circuit requiring a 2.2kΩ axial resistor element
- No special software, firmware, or protocol dependencies
