Overview
The OMEGA XCIB-K-4-2-10 is a high-temperature Type K thermocouple assembly engineered for continuous measurement in furnaces, ovens, and other industrial heating processes. With a 10-foot lead and exposed junction design, this thermocouple delivers reliable temperature monitoring up to 980°C (1800°F) continuous service and 1090°C (2000°F) short-term service, making it ideal for process control in heavy industrial environments.
Key Features
- Inconel 600® Overbraid: Double-protected design with tough, high-nickel content alloy for abrasion resistance and durability in harsh environments
- Nextel® Ceramic Fiber Insulation: 20-gauge solid conductor wires insulated with ceramic fiber for consistent performance at extreme temperatures
- Exposed Junction (Style 2): Fast response time for rapid temperature sensing in direct contact with process media
- 10-Foot Lead Length: Provides adequate distance from heat sources for safe controller placement and integration into control panels
- ANSI Standard Limits of Error: Type K thermocouple meets standard accuracy specifications for industrial measurement
Technical Specifications
- Thermocouple Type: Type K
- Temperature Range: 0°C to 980°C (32°F to 1800°F) continuous; 1090°C (2000°F) short-term
- Lead Length: 10 feet (3 meters / 120 inches)
- Wire Gauge: 20 AWG solid conductor
- Insulation: Nextel® ceramic fiber with Inconel 600® overbraid
- Junction Style: Exposed junction (Style 2)
- RoHS Compliant: Yes
- Series: XCIB (High Temperature Inconel Overbraided)
Typical Applications
- Industrial furnace and oven temperature monitoring and control
- Process profiling and thermal mapping in production environments
- Conveyor-based heating systems and thermal processing lines
- Heat treat furnaces and annealing ovens
- Direct flame contact applications where durable insulation is critical
Compatibility & Replacements
Compatible With
- OMEGA temperature controllers and process control systems accepting Type K thermocouples
- Standard industrial PLC and DCS systems with thermocouple input modules
- Any measurement device or data acquisition system configured for Type K thermocouples
- Furnace control loops and temperature monitoring systems
Replaces / Drop-In Replacement For
- Other XCIB-K series thermocouples with exposed junction configuration (refer to OMEGA documentation for specific part number cross-references)
- Legacy Type K thermocouple assemblies requiring upgrade to higher temperature capability
Works With
- Type K thermocouple input modules in industrial controllers
- Thermocouple conditioners and signal processors
- SCADA and data logging systems supporting Type K calibration
- Industrial measurement and control software platforms
