Overview
The Wika 9834800 (model 232.34) is a pressure gauge engineered for industrial process measurement in demanding environments. WIKA type 232.34 mechanical pressure gauges represent the industry standard and are designed to provide lasting service in extreme operating conditions when properly applied. 4.5 or 6 inch pressure gauges with thermoplastic housing for use in adverse service conditions where pulsating or vibration exists. This model combines robust construction with precision measurement, making it suitable for chemical, petrochemical, power generation, and plant engineering applications.
Key Features
- Excellent load-cycle stability and shock resistance
- Solid front thermoplastic case with black fiberglass reinforcement
- 316 SS wetted parts, 0.5% of span accuracy, solid-front, blow-out back safety case
- Positive pressure range 0–15 PSI—easy-to-read 4.5″ dial
- All lower mount connection gauges are factory prepared for case filling
- Liquid-fillable option available for high pulsation applications
Technical Specifications
See detailed specs in the table below. All measurements verified from distributor and manufacturer sources.
Typical Applications
- Chemical and petrochemical processing
- Power generation and utility monitoring
- Mining and resource extraction
- Environmental technology and waste treatment
- Mechanical engineering and plant construction
- Compressed air and hydraulic system monitoring
Compatibility & Replacements
Compatible With
- 1/2″ NPT process connections (lower mount)
- Dry and liquid-fillable gauge applications
- Industrial automation systems with mechanical pressure monitoring
- Pulsating pressure environments (with optional liquid fill)
- Corrosive media exposure in process industries
Replaces / Drop-In Replacement For
The Wika 9834800 is the current part number for this specific 232.34 configuration. Verify compatibility with your system integrator before ordering replacement gauges, as alternative WIKA models (such as 233.34 series) may offer different specifications.
Works With
- Standard 1/2″ NPT threaded connections
- Low-pressure process systems (0–15 PSI)
- Both gaseous and liquid media applications (non-obstructing)
- Systems with high dynamic loads and vibration
- Chemical-compatible media systems (refer to WIKA chemical compatibility table)
