Overview
The Ashcroft 25-1009AW-02B-30 is a Duralife industrial pressure gauge designed for critical monitoring in chemical, petrochemical, oil & gas, and water treatment applications. With a 0-30 PSI pressure range and 3.5″ dial, this gauge combines durable stainless steel construction with advanced movement technology to withstand shock, vibration, and pulsation.
Key Features
- PowerFlexâ„¢ Movement: Superior resistance to shock, vibration and pulsation
- True Zeroâ„¢ Technology: Reduces reading errors by using “zero box” instead of conventional dial pins
- IP65 Rating: IP65 Rating and NEMA 4X protection
- Stainless Steel Case: 304 stainless steel case with polycarbonate window for corrosion resistance
- Field Fillable: Field fillable design for easy maintenance
- Aluminum Bronze Connection: Aluminum bronze process connection material with 316L Stainless Steel Bourdon Tube
Technical Specifications
- Pressure Range: 0-30 PSI
- Model Number: 1009AW (Duralife series)
- Part Number: 25-1009AW-02B-30
- Dial Size: 3.5 inches
- Case Material: 304 stainless steel
- Bourdon Tube Material: 316L stainless steel
- Process Connection Material: Aluminum bronze
- Window Material: Polycarbonate
- Connection Type: Lower center back (02B configuration)
- Temperature Rating (Ambient): -40°F to 200°F (-40°C to 93°C) dry
- Temperature Rating (Process): -40°F to 250°F (-40°C to 121°C)
- Protection Rating: IP65 / NEMA 4X
- Approvals: CRN Approved and PED compliant
- Condition: New in box
Typical Applications
The Ashcroft 25-1009AW-02B-30 is ideal for:
- Chemical and petrochemical processing plants
- Oil & gas production and distribution
- Water and wastewater treatment facilities
- HVAC and refrigeration systems
- Compressed air and gas monitoring
- Industrial process control requiring low-range pressure measurement
Compatibility & Replacements
Compatible With
- Standard industrial pneumatic and hydraulic systems
- U-clamp and front flange mounting options
- Threaded process connections for direct panel installation
- Systems requiring IP65 / NEMA 4X rated instrumentation
Replaces / Drop-In Replacement For
- Ashcroft 95422 (legacy model designation)
- Previous generation 1009 gauges with identical connection specifications
- OEM equipment calling for Ashcroft Duralife 0-30 PSI gauges
Works With
- Any pneumatic or hydraulic system with standard process connections
- Panel-mounted instrumentation assemblies
- Mobile and stationary industrial equipment
- Compatible with snubbers and isolators for high-vibration environments
