Overview
The Vacon X5C20150C is an AC variable frequency drive (VFD) engineered for reliable industrial motor speed control. Listed in the Vacon X Series product lineup, this drive delivers 15 HP of continuous output capacity and is built to withstand harsh industrial environments. The VACON X Series has reached the Limited phase of its lifecycle, making quality surplus units valuable for maintenance and replacement applications.
Key Features
- Rated Output: 15 HP continuous duty performance
- Industrial-Grade Construction: Built to withstand knocks, bumps and vibrations of industrial workplaces and washdowns with directed water at 1000 PSI from 6 feet away
- Control Modes: V/Hz control with options for Linear, pump, fan, or 2-piece linear profiles; also supports sensorless vector (SVC)
- Programmable Operation: Carrier frequency programmable 1–16 kHz (8 kHz max for higher power models)
- Extended Temperature Range: Rated for indoor/outdoor use in harsh environments including low-temperature operation to -10°C with Arctic Mode activation
- Dynamic Braking Support: Optional external brake resistor configuration available
Technical Specifications
The X5C20150C is part of the X5 frame-size range and delivers consistent performance across standard industrial voltage configurations. Detailed terminal specifications and wiring requirements are documented in the comprehensive Vacon X5 user manual.
Typical Applications
- HVAC and refrigeration systems (pump and fan control)
- Industrial compressor and blower drives
- Centrifugal and positive displacement pump applications
- General-purpose motor speed control in manufacturing
- Water treatment and wastewater handling
- Food processing and packaging machinery
Compatibility & Replacements
Compatible With
- Three-phase AC induction motors (standard industrial ratings)
- Pump and fan load profiles via programmed control curves
- External brake resistor modules for dynamic braking applications
- Standard industrial control panels and wiring practices
Replaces / Drop-In Replacement For
The X5C20150C is part of the Vacon X Series family. For specific model replacement compatibility, verify part specifications with your system integrator or controls engineer before ordering, as drop-in compatibility depends on voltage rating, terminal configuration, and control logic customization.
Works With
- Vacon X5 control board programming interface
- V/Hz and sensorless vector control algorithms
- Field wiring per NEMA standards (120V/230V/480V AC control signals)
- Dynamic braking resistor modules and optional encoder feedback
- Standard industrial control networks and relay logic
