Overview
The Toshiba C-20E magnetic contactor is an industrial-duty AC switching device designed for motor control and circuit switching applications. Rated at NEMA Size 00+ with 20A continuous current capacity at 600V AC maximum, the C-20E delivers reliable contact closure and holds up under frequent cycling in demanding environments. This contactor features a 3-pole configuration and is certified by UL, CSA, and IEC standards, making it suitable for North American and international installations.
Key Features
- NEMA Size 00+ compact form factor for space-constrained panels
- 20A continuous current rating at 600V AC maximum
- 3-pole contact configuration for three-phase motor control
- Bracket mount design for standard enclosure integration
- UL, CSA, and IEC 60947-4-1 certified for safety compliance
- AC-20 utilization category for general-purpose switching
Technical Specifications
- Coil voltage options: 110/120V AC standard (480V AC variants available)
- Contact configuration: 3-pole main contacts
- Rated current: 20A continuous
- Maximum voltage: 600V AC
- Mounting: Bracket mount
- IEC utilization category: AC-20
- Certifications: UL, CSA, IEC
Typical Applications
The Toshiba C-20E is ideal for:
- Three-phase fractional and low-horsepower motor starters
- Lighting panel and HVAC control circuits
- Machine tool and production equipment starter circuits
- Industrial automation switching and load control
- Retrofit and replacement applications in legacy systems
Compatibility & Replacements
Compatible With
- Standard NEMA-rated motor control centers and starter enclosures
- Three-phase AC induction motors rated 600V or less
- IEC 60947-4-1 compliant control systems
- Bracket-mount contactor wiring schemes
- Standard industrial control logic and push-button stations
Replaces / Drop-In Replacement For
- Toshiba C-20 (earlier variant)
- Toshiba C20A
- Other NEMA Size 00+ 20A 3-pole AC contactors in 600V applications
Works With
- Standard electromechanical control relay logic
- IEC 60947-4-1 control protocols
- AC600V distribution systems
- NEMA-standard motor control center wiring
- Bracket-mounted contactor assemblies and kits (such as CMK-20E)
