Overview
The Texas Instruments 2207164 TIGRAPH is a dedicated chart recorder and plotter built for reliable data acquisition and process visualization. This used-condition unit is fully functional and ideal for test, measurement, inspection, and data logging applications where continuous analog recording is required. The TIGRAPH series earned its reputation for durability and accuracy in industrial and scientific settings, making it a dependable choice for retrofit installations, laboratory upgrades, or cost-sensitive data acquisition needs.
Key Features
- Dedicated chart recorder and plotter for continuous analog data acquisition
- Compact design suitable for rack mounting or standalone installation
- Reliable pen-and-paper recording mechanism for permanent data documentation
- Industrial-grade construction for laboratory and process monitoring applications
- Used condition—verified functional and ready to deploy
Technical Specifications
Exact specifications for input voltage, recording range, chart speed, and dimensional details should be verified with the unit’s manual or a qualified technician prior to installation. Typical vintage TIGRAPH models support multiple analog input channels, fixed or variable chart speeds, and standard 110/220 VAC power operation.
Typical Applications
- Continuous process temperature and pressure monitoring
- Laboratory data logging and experiment documentation
- Equipment performance trending and diagnostics
- Compliance-grade analog recording for auditable records
- Retrofit installations where digital conversion is not yet feasible
Compatibility & Replacements
Compatible With
- Standard industrial analog output signals (voltage and current loops)
- Laboratory power distribution systems (110/220 VAC)
- Chart paper and pen consumables typical of vintage Texas Instruments recorders
Replaces / Drop-In Replacement For
The Texas Instruments 2207164 is a used original-equipment unit. Verify with your system integrator or instrument specialist whether this model directly replaces other Texas Instruments TIGRAPH variants or competing chart recorder models in your application.
Works With
- Standard chart paper rolls and recording pens compatible with vintage Texas Instruments TIGRAPH models
- Analog signal sources (thermocouple transmitters, pressure transducers, current loop outputs)
- Legacy industrial control and monitoring systems
