Overview
The Telemecanique LA1-LC010 is an integral auxiliary contact block designed for use with Tesys Integral motor starters and contactors. This Type LD contact block provides reliable auxiliary switching for status monitoring and control interlocking in industrial automation applications. The LA1-LC010 is commonly paired with larger Tesys Integral starters to add supplementary contact capability for logic and safety circuits.
Key Features
- Type LD integral starter auxiliary contact block
- 2 normally open (NO) + 1 normally closed (NC) contact configuration
- Rated for 6 amp at 690 VAC, 600 VAC compatible
- Screw clamp terminal attachment for secure wire connection
- Instantaneous response with no intentional delay
- Compact design for direct mounting on Tesys Integral contactor base
Technical Specifications
- Contact Configuration: 2 NO + 1 NC
- Rated Current: 6 A
- Rated Voltage: 690 VAC (600 VAC operation supported)
- Terminal Type: Screw clamp
- Contact Type: Instantaneous
- Product Type: Auxiliary contact block
- Series: Tesys Integral
- Mounting: Base mount (direct attachment to contactor)
Typical Applications
The LA1-LC010 is typically integrated with Telemecanique/Schneider Electric motor starters for:
- Auxiliary control and status signaling in motor control circuits
- Interlocking and safety logic in multi-motor systems
- PLC input feedback from contactor position
- Pilot circuit control in industrial machinery
- HVAC and pump station automation
- Manufacturing equipment control integration
Compatibility & Replacements
Compatible With
- Telemecanique LD4 series contactors (LD4-LC030, LD4-LC060, etc.)
- Tesys Integral motor starters with LA1 auxiliary contact mounting
- Schneider Electric legacy motor control assemblies
- Industrial control panels operating at 600-690 VAC
- Traditional hardwired motor starter circuits
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering. The LA1-LC010 is a direct auxiliary contact block for Telemecanique Tesys Integral starters; ensure your contactor base supports LA1 series auxiliary contact mounting.
Works With
- Telemecanique LD4 series contactors and starters
- Schneider Electric Tesys Integral platform
- Standard industrial control relays and pilot devices
- Hardwired and semi-automated motor control systems
- Legacy 600/690 VAC industrial automation equipment
