Overview
The Telco SMP 7600 TP J (part number 0477111300) is a diffuse proximity photoelectric sensor from the SpaceMaster 7000 series. This self-contained M18 barrel sensor delivers reliable object detection with a 0.5 m sensing range and 2 ms response time. Built-in potentiometer sensitivity adjustment and M12 4-pin plug connection simplify installation in industrial automation, manufacturing, and process control applications.
Key Features
- Diffuse proximity detection with 0.5 m operating range
- Adjustable sensitivity via integral potentiometer
- Switchable NPN/PNP output with NO/NC functionality
- M12 4-pin connector for quick-disconnect installations
- 10–30 VDC operating voltage range
- IP67 rated housing for washdown and outdoor environments
- Reverse polarity protection on power and signal lines
Technical Specifications
- Sensing Method: Diffuse Proximity Photoelectric
- Sensing Range: 0.5 m
- Response Time: 2 ms
- Supply Voltage: 10–30 VDC
- Output Configuration: NPN/PNP switchable, NO/NC
- Housing Material: Polycarb M18 × 1
- Connector Type: M12 A-coded, 4-pin plug
- IP Rating: IP67
- Series: SpaceMaster 7000 (SMP—diffuse type)
- Part Number: 0477111300
Typical Applications
- Automated assembly line presence/absence detection
- Box and label sensing on conveyor systems
- Part counting and positioning in manufacturing
- Washdown and wet environment monitoring (IP67)
- Machine safety interlocks and motion control
- Packaging and logistics automation
Compatibility & Replacements
Compatible With
- Standard industrial PLC and motion controller inputs (24 VDC discrete I/O)
- M12-compatible sensor wiring harnesses and panel connectors
- All automation platforms supporting discrete NPN/PNP sensor inputs
- Ethernet/IP and PROFIBUS networks via appropriate gateway modules
Replaces / Drop-In Replacement For
- Other SpaceMaster SMP 7600 diffuse sensors with equivalent specifications
- Legacy Telco photoelectric proximity models of similar form and function
- Verify compatibility with your system integrator before ordering.
Works With
- Allen-Bradley CompactLogix, ControlLogix, and SLC 500 discrete inputs
- Siemens S7-1200, S7-1500, and LOGO! controllers
- Mitsubishi FX and Q-series PLCs
- Omron CJ and CP series control systems
- Standard M12 sensor cabling and industrial control enclosures
