Overview
The Tectran 1926-05 is a premium-grade nylon air brake tubing engineered for heavy-duty truck, trailer, and industrial pneumatic applications. This 3/8″ OD tubing is supplied in a 500-foot bulk spool and meets rigorous DOT and SAE J844 standards for air brake system components. With a durable nylon construction, the Tectran 1926-05 airbrake tubing delivers consistent performance under demanding conditions.
Key Features
- 3/8″ outer diameter (OD) for standard airbrake system connections
- 500-foot spool length reduces splice joints and labor in large installations
- Rated for continuous operation at 150 PSI in air brake circuits
- Resistant to gasoline, diesel fuel, UV exposure, and road debris
- Flexible nylon construction maintains performance in extreme temperature ranges
- DOT and SAE J844 compliant for regulatory and safety certification
Technical Specifications
- Outside Diameter (OD): 3/8″
- Material: Nylon (reinforced)
- Color: Red
- Length: 500 feet per spool
- Operating Pressure: 150 PSI maximum
- Temperature Range: -40°F to +200°F (-40°C to +93°C)
- Standards: DOT compliant, SAE J844 Type B (reinforced)
- Series: Tectran 1926-05
- Coupling Style: Compression fitting compatible
Typical Applications
The Tectran 1926-05 is ideal for:
- Tractor and trailer air brake systems
- Pneumatic supply lines in heavy-duty trucks
- Industrial air brake circuits and control lines
- Replacement tubing in maintenance and repair operations
- OEM and aftermarket pneumatic system installation
Compatibility & Replacements
Compatible With
- Standard compression fittings for 3/8″ OD tubing
- DOT-rated push-to-connect fittings for nylon airbrake lines
- Air brake systems on heavy-duty trucks and trailers
- Industrial pneumatic control systems
- Tectran airbrake fitting kits and coupling assemblies
Replaces / Drop-In Replacement For
- Original equipment Tectran 1926-05 tubing
- Generic red 3/8″ OD nylon airbrake tubing (verify length and specifications)
Works With
- SAE J844 Type B rated compression fittings
- DOT air brake system components
- Standard trailer brake control modules
- Pneumatic push-in connectors and elbow fittings
