Overview
The Swann SWPRO-530CAM is a multi-purpose day/night security camera designed for versatile surveillance in both indoor and outdoor environments. Built on analog technology with 600 TVL resolution and a 1/3″ SwannTruColor (STC) video sensor, this wired bullet camera delivers clear, detailed footage suitable for DVR-based security systems. The unit features ICR (infrared cut filter removal) technology and infrared illumination, making it ideal for 24-hour monitoring in low-light and complete darkness scenarios.
Key Features
- 600 TVL Resolution — delivers clear and crisp footage at 600 TVL with a wide viewing angle
- Day/Night ICR Function — switches between color and B&W as per changes in ambient lighting ensuring accurate color reproduction in daylight and enhanced B&W images at night
- IR Illumination — equipped with 24 IR LEDs (effective up to 65′ / 20 m)
- 4.8mm Fixed Lens — 4.8mm lens with a 58° viewing angle for balanced coverage in medium-sized spaces
- IP67 Weatherproof — IP67 durable weatherproof metal casing in any weather
- Image Adjustment Features — Wide Dynamic Range, White Balance and Backlight Compensation that compensates for high-contrast light, back light, glare and light-reflective environments
Technical Specifications
- Resolution: 600 TVL, 728 x 488 pixels
- Video Sensor: 1/3″ SwannTruColor (STC) CCD
- Lens: 4.8mm fixed focal length
- Field of View: 58°
- IR Illumination: 24 LEDs, effective range 65′ (20 m)
- Night Vision: Yes, infrared technology
- Signal Format: NTSC and PAL
- Housing: IP67-rated weatherproof metal casing
- Shutter Speed: 1/100,000 seconds
- Minimum Illumination: 0 lx (complete darkness with IR)
- White Balance: Auto
- Camera Type: Bullet, wired
Typical Applications
The SWPRO-530CAM is well-suited for residential and small commercial surveillance installations requiring reliable analog CCTV monitoring:
- Home security systems and perimeter monitoring
- Retail store and business premises surveillance
- Parking lot and outdoor area monitoring
- Building entry and lobby surveillance
- Warehouse and storage facility monitoring
- Remote property monitoring with DVR recording
Compatibility & Replacements
Compatible With
- Standard analog CCTV DVR systems (BNC connector)
- TV displays with yellow video-in RCA connectors
- NTSC and PAL video standards
- Analog surveillance monitoring networks
Replaces / Drop-In Replacement For
The SWPRO-530CAM is a direct replacement for earlier Swann Pro series bullet cameras in existing analog CCTV installations using standard BNC/RCA connections. Verify connector compatibility and mounting hardware with your existing system before ordering.
Works With
- Swann DVR8 and other Swann analog DVR systems
- Third-party analog CCTV DVRs supporting standard NTSC/PAL video
- CCTV monitoring software compatible with analog BNC feeds
- IP converter boxes for integration into modern network systems
