Overview
The Ashcroft SM-023616 receiver gauge is a pneumatic receiver gauge engineered for industrial pressure measurement applications. Ashcroft receiver gauges are used in conjunction with pneumatic transmitters to indicate pressure, temperature, flow or other process parameters that can be transmitted by proportional variations in air pressure. This unit features a 0-250 PSI dial range with a maximum input pressure rating of 25 PSI, making it suitable for low-to-medium pressure applications in pneumatic control systems.
Key Features
- 0-250 PSI dial range with 25 PSI maximum input pressure specification
- Pneumatic receiver design compatible with proportional air pressure signal transmission
- Industrial-grade construction for reliable long-term operation
- Direct pressure indication from pneumatic transmitter signals
- Suitable for process monitoring and system diagnostics in pneumatic control circuits
Technical Specifications
The following specifications are based on the Ashcroft SM-023616 designation:
| Model Number | SM-023616 |
| Manufacturer | Ashcroft |
| Gauge Type | Pneumatic Receiver Gauge |
| Dial Range | 0-250 PSI |
| Maximum Input Pressure | 25 PSI |
| Product Category | Pressure Gauges |
Typical Applications
The Ashcroft SM-023616 receiver gauge is used in:
- Pneumatic transmitter indicator systems
- Industrial control circuit pressure monitoring
- Process measurement feedback loops
- Compressed air system diagnostics
- Manufacturing equipment pressure verification
Compatibility & Replacements
Compatible With
- Ashcroft pneumatic transmitters
- Standard pneumatic control systems
- Industrial pressure signal transmission networks
- Proportional air pressure indicator systems
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator or equipment manufacturer before ordering as a replacement.
Works With
- Pneumatic transmitter signal conditioning
- Proportional pressure control circuits
- Industrial automation and process control systems
