Overview
The Siemens ED23B100 Type ED2 Sentron Molded Case Circuit Breaker is a heavy-duty electrical protection device engineered for industrial and commercial control applications. With a rated current of 100A at 240VAC, this 3-pole breaker provides dependable overload and short-circuit protection using a thermal-magnetic trip mechanism. The ED2 frame design offers excellent performance in demanding environments where rapid fault clearance is essential.
Key Features
- Thermal-Magnetic Trip Unit: Combines time-delay thermal protection for overloads with instantaneous magnetic protection for short circuits
- 3-Pole Configuration: Provides simultaneous protection on all three phases of three-phase power distribution
- 100A Rated Current: Matches most standard motor control center and panelboard applications
- 10 kA Interrupt Rating: Safely interrupts faults at 240VAC per UL 489 standard
- Load Lug Connections: Simplifies field wiring with integral load-side lugs for 10 to 1/0 AWG wire (copper or aluminum)
- Compact ED Frame: Space-efficient design that fits standard industrial control cabinets
Technical Specifications
The ED23B100 meets stringent UL 489 and CSA 22.2 standards, ensuring reliability in mission-critical applications.
