Overview
The Sick MZT6 magnetic cylinder sensor (part number MZT6-03VPS-KR0, 1023972) is a non-contact proximity sensor engineered for reliable position detection on pneumatic cylinders. It detects magnetic piston positions within pneumatic or hydraulic actuators equipped with standard T-slot mounting rails, making it essential for automated production lines, assembly equipment, and fluid power applications.
Key Features
- 60 mm sensing range: Non-contact detection from distance, eliminating mechanical wear
- PNP switching output: Direct integration with standard industrial controls and PLCs
- Compact cuboid housing: Durable plastic construction with strong retaining force for reliable mounting
- T-slot cylinder compatibility: Drop-in mounting design for standard pneumatic cylinders with C-slots
- IP 69K enclosure rating: Full protection against dust, jets, and high-pressure washdown environments
- Safe switching point detection: Consistent and repeatable position signal for precise automation
Technical Specifications
| Part Number | MZT6-03VPS-KR0 |
| Alternate Part Number | 1023972 |
| Sensor Type | Magnetic Proximity Sensor |
| Supply Voltage | 30 V DC |
| Max Supply Current | ≤ 10 mA |
| Output Type | PNP (NPN available on related models) |
| Max Output Current | ≤ 100 mA |
| Sensing Range | 60 mm |
| Hysteresis | ≤ 0.1 mT |
| Enclosure Rating | IP 69K (EN 60529) |
| Housing Material | Plastic cuboid |
| Mounting | T-slot cylinder (C-slot compatible) |
| Protection Features | Wire-break protection, short-circuit protection, reverse polarity protection, power-up pulse suppression |
| Manufacturer | Sick |
Typical Applications
- Pneumatic actuator position detection in manufacturing automation
- Hydraulic cylinder end-of-stroke signaling
- Assembly machine clamping verification
- Industrial packaging and bottling equipment
- CNC machine tool coolant systems with magnetic piston feedback
- Automated material handling and conveyor systems with pneumatic control
Compatibility & Replacements
Compatible With
- Allen-Bradley PLCs and control modules accepting PNP sensor inputs
- Siemens S7 series and SIMATIC systems with 24 V DC logic
- Mitsubishi FX and Q series programmable logic controllers
- Omron CP and CJ series automation controllers
- Standard industrial PLC analog/discrete input modules with PNP sensing capability
- Pneumatic and hydraulic fluid power systems with T-slot mounting
Replaces / Drop-In Replacement For
Verify compatibility with your system integrator before ordering alternative models. Related Sick MZT6 variants include KW0, KPO, and KWX configurations for different output types and certifications.
Works With
- Studio 5000 (Allen-Bradley) discrete input modules
- TIA Portal (Siemens) configuration for sensor input
- GX Works (Mitsubishi) automation software
- Standard 24 VDC industrial automation wiring harnesses
- IP 69K-rated enclosures and washdown-rated cabinets
